8N-8625 LINES GP-AIRS/N 81Z5000-14500

Group No: 8N-8625
Part NumberPart NameQty
5P57001 SEAL-O-RING8
4N85232 PIPE-OUTLET (LH)1
3B19153 BOLT (3/8-16X1.375-IN)8
5M28944 WASHER-HARD (10.2X18.5X2.5-MM THK)8
4N13205 GASKET (ADAPTER)2
3N33686 PIPE-EXHAUST1
5B26387 BOLT (3/8-16X5.25-IN)2
7N22778 COUPLING-EXHAUST2
2M84119 STUD-TAPERLOCK (80-MM)1
4N184910 TUBE-AIR2
4N867711 PIPE-OUTLET (RH)1
3J538912 PLUG (EXTERNAL)2
6N714913 SUPPORT-ELBOW1
0L207014 BOLT (3/8-16X2.25-IN)2
5B789015 PLUG-PIPE2
8N862916 ELBOW-EXHAUST1
7E390117 TUBE (EXHAUST)1
8N087918 CLAMP4
8N087819 CLAMP2
8N0886SEAL-EXHAUST2
7E390620 TUBE (EXHAUST RH)1
9F899921 BOLT (3/8-16X7-IN)1
0S161922 BOLT (3/8-16X3-IN)4
1D471723 NUT (3/8-16-THD)3
1A596424 BOLT (3/8-16X4.5-IN)1
6N715225 SUPPORT-ELBOW1
1A518326 BOLT (3/8-16X4.75-IN)3
8N862627 ELBOW-EXHAUST1
0L114328 BOLT (3/8-16X2.5-IN)3
7E390729 TUBE (EXHAUST LH)1
1A202930 BOLT (3/8-16X1.125-IN)2
1D471931 NUT-FULL (1/2-13-THD)4
0S158732 BOLT (1/2-13X1.75-IN)4
6N673333 SUPPORT-HOUSING (LH)1
0S159134 BOLT (3/8-16X1.5-IN)4
0S160835 BOLT (3/8-16X3.75-IN)2
6N673436 SUPPORT-HOUSING (RH)1
1W048137 RING-EXHAUST SEAL2
5P585538 BOLT-12 POINT HEAD (1/2-13X1.75-IN)2
2M0849WASHER-HARD (13.5X25.5X5-MM THK)2
2W079639 SUPPORT-EXHAUST PIPE1
0T057340 BOLT (3/8-16X2.75-IN)3
0L135241 BOLT (3/8-16X3.25-IN)4
0L114342 BOLT (3/8-16X2.5-IN)1
