System And Components
122-3222 DRIVE GP-FANS/N 5ER1-UP
Group No: 122-3222
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N4036 | 1 PULLEY-FAN DRIVE (4-GROOVE) | 1 | |
| 8N9766 | 2 SPACER | 1 | |
| 8N9764 | 3 HUB-FAN PULLEY | 1 | |
| 8N9765 | 4 SPACER (52X70X66-MM THK) | 1 | |
| 0S1571 | 5 BOLT (3/8-16X1.75-IN) | 6 | |
| 1T0210 | 6 BALL BEARING | 2 | |
| 2W1660 | 7 ADAPTER-FAN | 1 | |
| 1D4624 | 8 BOLT (3/4-10X9-IN) | 1 | |
| 8N9768 | 9 WASHER-RETAINING (20.5X75X25-MM THK) | 1 | |
| 5F3144 | 10 SEAL-O-RING (120.24MM ID) | 1 | |
| 3B1915 | 11 BOLT (3/8-16X1.375-IN) | 6 | |
| 7X7730 | 12 PLUG-PIPE | 1 | |
| 4D8123 | 13 CLIP (LOOP)(7.94MM ID) | 2 | |
| 5P5299 | 14 SEAL-LIP TYPE | 1 | |
| 3B6552 | 15 ELBOW-PIPE | 1 | |
| 6U1989 | 16 VALVE-RELIEF | 1 | |
| 5K5959 | 17 SEAL-O-RING (50.17MM ID) | 1 | |
| 1W0424 | 18 BRACKET AS-FAN | 1 | |
| 3B8686 | 19 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 3G0570 | 20 HOSE AS | 1 | |
| 0S0509 | 21 BOLT (3/8-16X0.75-IN) | 1 | |
| 9L9132 | 22 WASHER-HARD (10.2X25.5X2.5-MM THK) | 1 | |
| 8S3887 | 23 BOLT (1/2-13X11-IN) | 2 | |
| 5P8245 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9X8878 | 25 BOLT (1/2-13X5.25-IN) | 2 | |
| 1W0422 | 26 V-BELT SET (INCLUDES 4-BELTS)(FAN DRIVE) | 1 |
