System And Components
8N-7174 GEAR GP-FRONTS/N 2GR1-743
Group No: 8N-7174
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2W2895 | 1 GEAR-CRANKSHAFT (92-TEETH) | 1 | |
| 3S1307 | 2 BOLT-12 POINT HEAD (3/8-16X2-IN) | 12 | |
| 7E0274 | 3 GEAR AS-IDLER (53-TEETH) | 1 | |
| 7N5243 | 3A BUSHING | 1 | |
| 7C3260 | 4 SHAFT | 1 | |
| 8M5255 | 5 SEAL-O-RING | 2 | |
| 7C3258 | 6 WASHER AS-THRUST | 1 | |
| 7N2047 | 6A DOWEL | 1 | |
| 1D4572 | 7 BOLT (1/2-13X5.5-IN) | 2 | |
| 0T0055 | 8 BOLT (3/8-16X4.25-IN) | 1 | |
| 7E0275 | 9 GEAR-WATER PUMP DRIVE (69-TEETH) | 1 | |
| 6K3771 | 10 BOLT-12 POINT HEAD (7/16-14X1.5-IN) | 12 | |
| 7N5239 | 11 SHAFT AS-PUMP DRIVE | 1 | |
| 8T2153 | 11A SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 7N5263 | 12 ADAPTER AS-PUMP (OIL) | 1 | |
| 1275400 | 12A BUSHING | 1 | |
| 1T0132 | 13 SEAL-O-RING | 1 | |
| 3B8453 | 14 SEAL-O-RING | 1 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 7 | |
| 7N5246 | 16 WASHER-THRUST | 2 | |
| 4B3388 | 17 BOLT (5/16-18X1.125-IN) | 4 | |
| 7N5245 | 18 ADAPTER AS-PUMP (WATER) | 1 | |
| 1275400 | 18A BUSHING | 1 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 5P8245 | 20 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 5R7137 | 21 WASHER-SEALING | 2 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 5R7136 | 23 WASHER-SEALING | 1 |
