System And Components
583-9493 CYLINDER HEAD ASS/N TXH1564-UP
Group No: 583-9493
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5362063 | 1 GUIDE-VALVE | 24 | |
| 2165582 | 2 BUSHING (STANDARD) | 7 | |
| 2170751 | BUSHING (0.25-MM OS) | ||
| 2170752 | BUSHING (0.762-MM OS) | ||
| 2613429 | BUSHING (1.778-MM OS) | ||
| 2613430 | BUSHING (1.27-MM OS) | ||
| 2634920 | 3 SLEEVE-INJECTOR (INLET) | 6 | |
| 2803979 | 4 INSERT-VALVE SEAT (INLET) | 12 | |
| 2884881 | INSERT-VALVE SEAT (0.51-MM OS, INLET) | ||
| 2884882 | INSERT-VALVE SEAT (0.76-MM OS, INLET) | ||
| 1662904 | 5 SEAL-O-RING | 12 | |
| 3003565 | 6 INSERT-VALVE SEAT (EXHAUST) | 12 | |
| 3B0623 | 7 PLUG-CUP (25.73-MM OD) | 17 | |
| 3B0645 | 8 PLUG-CUP (32.08-MM OD) | 20 | |
| 4483297 | 9 HEAD-CYLINDER | 1 | |
| 8T6757 | 10 PLUG-PIPE | 3 | |
| 9X7430 | 11 SEAL-O-RING | 6 |
