System And Components
152-1031 AIR COMPRESSOR GPS/N 7TR3644-UP
Group No: 152-1031
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3537954 | 1 GROMMET | 1 | |
| 5T8088 | 2 HOSE AS | 1 | |
| 4786619 | 3 HOSE AS | 1 | |
| 8B2026 | 4 SPACER (0.438X0.75X1.5-IN THK) | 1 | |
| 9S8752 | 5 NUT-FULL (3/8-16-THD) | 1 | |
| 8N2811 | 6 GASKET | 1 | |
| 9N5221 | 7 HOSE AS | 1 | |
| 1521005 | 8 HOSE AS | 1 | |
| 1609820 | 9 AIR COMPRESSOR GP | 1 | |
| 0054173 | 10 ELBOW | 1 | |
| 1187809 | 11 PLATE | 1 | |
| 0321269 | 12 ELBOW | 1 | |
| 0S1595 | 13 BOLT (1/2-13X1.25-IN) | 4 | |
| 0T0573 | 14 BOLT (3/8-16X2.75-IN) | 1 | |
| 1S0994 | 15 CLIP (LOOP) | 1 | |
| 2M9780 | 16 SEAL-O-RING | 2 | |
| 5P4592 | 17 ELBOW-FLARED | 1 | |
| 2N3378 | 18 ELBOW-FLARED | 1 | |
| 5M2894 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P4295 | 20 CLIP | 2 | |
| 5P8245 | 21 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 0321268 | 22 CONNECTOR (90-DEG) | 1 | |
| 7L7262 | 23 ELBOW-FLARED | 1 | |
| 8T1889 | 24 CLIP (SLOT) | 1 | |
| 8M0755 | 25 ADAPTER | 1 | |
| 8T1890 | 26 CLIP (TAB) | 1 | |
| 8T6757 | 27 PLUG-PIPE | 4 | |
| 9M4584 | 28 CONNECTOR | 1 | |
| 0S1594 | 29 BOLT (3/8-16X1-IN) | 1 |
