System And Components
160-9820 AIR COMPRESSOR GPS/N 7TR3631-UP
Group No: 160-9820
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4540 | 1 BOLT (5/16-18X2.75-IN) | 20 | |
| 8N4727 | 2 PISTON AS-COMPRESSOR | 4 | |
| 1W2803 | PLUG | 2 | |
| 7W6492 | 3 PLUG-PIPE (1/2-14-THD) | 4 | |
| 3H7311 | 4 GASKET-CYLINDER BLOCK | 2 | |
| 9M0378 | 5 BOLT (5/16-18X2.87-IN) | 2 | |
| 3B4505 | 6 LOCKWASHER | 10 | |
| 2B2695 | 7 BOLT (5/16-18X0.875-IN) | 5 | |
| 8T6764 | 8 PLUG-PIPE (1/8-27-THD) | 2 | |
| 7F2742 | 9 BALL BEARING | 1 | |
| 8T9364 | 10 BOLT (1/4-20X0.625-IN) | 8 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 12 | |
| 3B4506 | 12 LOCKWASHER | 12 | |
| 3H5162 | 13 RETAINER | 1 | |
| 8H9789 | 14 BALL BEARING | 1 | |
| 5M6213 | 15 PLUG-PIPE (1/4-18-THD) | 2 | |
| 2S1218 | 16 GASKET-CYLINDER HEAD | 2 | |
| 8M7065 | 18 GASKET (AIR INLET) | 4 | |
| 0S1617 | 19 BOLT (5/16-18X0.75-IN) | 6 | |
| 2H3755 | 20 BOLT (5/16-18X0.43-IN) | 2 | |
| 6L1883 | 21 GASKET | 1 | |
| 9L2276 | 22 GUIDE-VALVE | 4 | |
| 9L2277 | 23 VALVE-INLET | 4 | |
| 9L2278 | 24 SPRING-VALVE | 4 | |
| 4N9680 | 25 GOVERNOR GP-AIR COMPRESSOR | 1 | |
| 8T7922 | 26 SCREW-HEX SOCKET (10-24X0.383-IN) | 3 | |
| 8T4205 | 27 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 8T6767 | 28 PLUG-PIPE (3/8-18-THD) | 8 | |
| 7W9827 | 29 ADAPTER | 1 | |
| 2192350 | 30 GASKET | 1 | |
| 5P4479 | 31 ELBOW (FLARED-LONG) | 1 | |
| 1170068 | 32 HOSE AS | 1 | |
| 6K1972 | 33 ELBOW-FLARED | 1 | |
| 5F5434 | 34 VALVE AS-VENT | 1 | |
| 3718029 | KIT-HEAD | 1 | |
| 2286581 | KIT-PISTON RING (AIR COMPRESSOR) | 1 | |
| 9M0402 | KIT-GOVERNOR OVERHAUL (AIR COMPRESSOR) | 1 | |
| 2095258 | KIT-BEARING (AIR COMPRESSOR) | 1 | |
| 2095242 | KIT-ROD (AIR COMPRESSOR) | 1 |
