121-5803 LINES GP-TURBOCHARGER OILS/N 7TR1-1043

Group No: 121-5803
Part NumberPart NameQty
8L27861 SEAL-O-RING2
6V45892 SEAL-O-RING4
10542963 HOSE AS2
10542974 HOSE AS2
2P12965 TEE2
7E99446 ADAPTER2
8T95357 BOLT-SOCKET HEAD (M8X1.25X60-MM)4
4P66458 BRACKET2
9S52829 WASHER-HARD (8.8X14.5X2-MM THK)4
2P763610 CONNECTOR (3/4-16 STR-THD)2
8S919111 BOLT (3/8-16X4-IN)4
9L913212 WASHER-HARD (10.2X25.5X2.5-MM THK)26
141716513 ADAPTER-OIL SUPPLY2
7E761414 BRACKET2
4P069215 CLAMP AS8
1081434GROMMET1
0L114316 BOLT (3/8-16X2.5-IN)(3/8-16X2.5IN)4
9S875217 NUT-FULL (3/8-16-THD)8
0S159418 BOLT (3/8-16X1-IN)(3/8-16X1IN)10
6M747619 ELBOW1
4P446020 GASKET2
7N755921 GASKET2
3B191522 BOLT (3/8-16X1.375-IN)2
0S160823 BOLT (3/8-16X3.75-IN)2
5P989024 SEAL-O-RING (23.16MM ID)4
6K553625 CLIP (TAB)2
6K553526 CLIP (SLOT)2
7E533527 BRACKET4
7N509428 ELBOW-DRAIN2
0S158829 BOLT (3/8-16X1.25-IN)(3/8-16X1.25IN)16
2W075230 GASKET4
7E233231 ELBOW-DRAIN2
6L169432 GASKET2
6V960733 BOLT (M8X1.25X120-MM)4
6V513434 SEAL-O-RING4
141712335 TUBE2
1W860136 ELBOW-DRAIN2
6K493537 CLIP (TAB)2
6K493438 CLIP (SLOT)2
9M458439 CONNECTOR1
061753940 SEAL-O-RING2
121581041 ELBOW-DRAIN2
141712542 TUBE2
