155-0503 LINES GP-TURBOCHARGER OIL -HIGH ALTITUDES/N 7TR1-732; 7TR825-1045

Group No: 155-0503
Part NumberPart NameQty
1W86011 ELBOW-DRAIN2
2W07522 GASKET4
4P06923 CLAMP AS4
1081434GROMMET1
4P44604 GASKET2
6K55355 CLIP (SLOT)2
6K55366 CLIP (TAB)2
7E53357 BRACKET4
7N50948 ELBOW-DRAIN2
7N75599 GASKET2
9M458410 CONNECTOR1
085809111 BOLT (M10X1.5X55-MM)4
105429612 HOSE AS2
105429713 HOSE AS2
121581014 ELBOW-DRAIN2
141712515 TUBE2
141716516 ADAPTER-OIL SUPPLY2
153751217 ELBOW-DRAIN2
153751318 TUBE2
155049619 GASKET2
175526920 ADAPTER2
061753921 SEAL-O-RING (20.22MM ID)2
0L114322 BOLT (3/8-16X2.5-IN)2
0S158823 BOLT (3/8-16X1.25-IN)16
0S159424 BOLT (3/8-16X1-IN)6
0S160825 BOLT (3/8-16X3.75-IN)2
2P129626 TEE2
2P763627 CONNECTOR (3/4-16 STR-THD)2
3B191528 BOLT (3/8-16X1.375-IN)2
4P664529 BRACKET2
5P989030 SEAL-O-RING4
6K493431 CLIP (SLOT)2
6K493532 CLIP (TAB)2
6M747633 ELBOW1
6V458934 SEAL-O-RING4
6V513435 SEAL-O-RING4
8L278636 SEAL-O-RING2
8S919137 BOLT (3/8-16X4-IN)4
8T953538 BOLT-SOCKET HEAD (M8X1.25X60-MM)4
9L913239 WASHER-HARD (10.2X25.5X2.5-MM THK)8
9S528240 WASHER-HARD (8.8X14.5X2-MM THK)4
9S875241 NUT-FULL (3/8-16-THD)6
9X645842 WASHER-HARD (10.2X22.5X3-MM THK)10
