Assembly
100%

155-0503 LINES GP-TURBOCHARGER OIL -HIGH ALTITUDES/N 7TR1046-UP

Group No: 155-0503
Part NumberPart NameQty
1W86011 ELBOW-DRAIN2
2W07522 GASKET4
4P06923 CLAMP AS4
1081434GROMMET1
4P44604 GASKET2
6K55355 CLIP (SLOT)2
6K55366 CLIP (TAB)2
7E53357 BRACKET4
7N50948 ELBOW-DRAIN2
7N75599 GASKET2
9M458410 CONNECTOR1
085809111 BOLT (M10X1.5X55-MM)4
121581012 ELBOW-DRAIN2
141712513 TUBE (TURBO OIL DRAIN)2
153751214 ELBOW-DRAIN2
153751315 TUBE (TURBO OIL DRAIN)2
155049616 GASKET2
163427517 ADAPTER (TURBO OIL SUPPLY)2
175526918 ADAPTER (ORIFICE)2
184323119 HOSE AS2
304234120 HOSE AS2
1463449COUPLING-PERMANENT1
1463450COUPLING-PERMANENT1
061753921 SEAL-O-RING2
0L114322 BOLT (3/8-16X2.5-IN)1
0S158823 BOLT (3/8-16X1.25-IN)16
0S159424 BOLT (3/8-16X1-IN)6
0S160825 BOLT (3/8-16X3.75-IN)2
5M289426 WASHER-HARD (10.2X18.5X2.5-MM THK)5
250149927 TEE2
2P763628 CONNECTOR (3/4-16 STR-THD)2
3B191529 BOLT (3/8-16X1.375-IN)2
4P664530 BRACKET2
5P989031 SEAL-O-RING4
6K493432 CLIP (SLOT)2
6K493533 CLIP (TAB)2
6M747634 ELBOW1
6V458935 SEAL-O-RING4
6V513436 SEAL-O-RING4
8L278637 SEAL-O-RING2
8S919138 BOLT (3/8-16X4-IN)4
8T953539 BOLT-SOCKET HEAD (M8X1.25X60-MM)4
9L913240 WASHER-HARD (10.2X25.5X2.5-MM THK)8
9M197441 WASHER-HARD (8.8X16X2-MM THK)4
9S875242 NUT-FULL (3/8-16-THD)6
9X645843 WASHER-HARD (10.2X22.5X3-MM THK)5
0T057344 BOLT (3/8-16X2.75-IN)1
