System And Components
416-9631 LINES GP-TURBOCHARGER WATERS/N 7TR3413-UP
Group No: 416-9631
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0707 | 1 CLAMP AS | 4 | |
| 3078373 | GROMMET | 1 | |
| 4P3563 | 2 CLAMP AS | 10 | |
| 1081434 | GROMMET | 1 | |
| 4P6645 | 3 BRACKET | 3 | |
| 4P6814 | 4 MANIFOLD | 2 | |
| 6T2723 | 5 BRACKET | 1 | |
| 7E7264 | 6 CONNECTOR | 4 | |
| 7N7878 | 7 PLATE-COVER | 2 | |
| 8R9137 | 8 ANGLE | 1 | |
| 1070766 | 9 MANIFOLD | 1 | |
| 1196299 | 10 BRACKET AS | 2 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 2 | |
| 1196300 | 11 PLATE AS | 2 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 1215805 | 12 TUBE AS-WATER | 1 | |
| 1215806 | 13 TUBE AS-WATER | 1 | |
| 1215807 | 14 TUBE AS-WATER | 2 | |
| 1566227 | 15 TUBE AS | 2 | |
| 1566228 | 16 TUBE AS | 2 | |
| 1634279 | 17 BLOCK | 2 | |
| 1874605 | 18 HOSE AS | 2 | |
| 3419211 | 19 GASKET | 4 | |
| 3532607 | 20 TUBE AS | 1 | |
| 3532608 | 21 TUBE AS | 1 | |
| 3532609 | 22 HOSE AS | 1 | |
| 3532610 | 23 HOSE AS | 1 | |
| 1195155 | 24 SEAL-O-RING | 8 | |
| 1808424 | 25 SEAL-O-RING | 5 | |
| 2949072 | 26 SEAL-O-RING | 12 | |
| 0L1143 | 27 BOLT (3/8-16X2.5-IN) | 3 | |
| 0L1351 | 28 BOLT (3/8-16X0.875-IN) | 4 | |
| 0L1352 | 29 BOLT (3/8-16X3.25-IN) | 4 | |
| 0L2070 | 30 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1594 | 31 BOLT (3/8-16X1-IN) | 1 | |
| 0S1618 | 32 BOLT (5/16-18X1-IN) | 4 | |
| 0S1619 | 33 BOLT (3/8-16X3-IN) | 4 | |
| 1A2029 | 34 BOLT (3/8-16X1.125-IN) | 6 | |
| 2721777 | 35 WASHER-HARD (11X18.5X15-MM THK) | 4 | |
| 2A4639 | 36 BOLT (3/8-16X1.625-IN) | 4 | |
| 2P7636 | 37 CONNECTOR (3/4-16 STR-THD) | 2 | |
| 2T2396 | 38 ELBOW | 2 | |
| 3B1915 | 39 BOLT (3/8-16X1.375-IN) | 4 | |
| 3B7259 | 40 ELBOW | 2 | |
| 4P9029 | 41 BRACKET | 2 | |
| 5M2894 | 42 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 6V3251 | 43 SEAL-O-RING | 11 | |
| 6V5138 | 44 SEAL-O-RING | 10 | |
| 6V6609 | 45 SEAL-O-RING | 4 | |
| 6V8639 | 46 CONNECTOR | 2 | |
| 6V8640 | 47 CONNECTOR | 1 | |
| 6V8721 | 48 ELBOW | 1 | |
| 6V8739 | 49 UNION | 1 | |
| 6V8783 | 50 TEE-FACE SEAL | 2 | |
| 6V8791 | 51 TEE-FACE SEAL | 1 | |
| 6V9032 | 52 TEE-O-RING | 3 | |
| 6V9832 | 53 CAP (ORFS) | 1 | |
| 8C6873 | 54 CONNECTOR | 2 | |
| 8C7312 | 55 ADAPTER | 2 | |
| 8S9191 | 56 BOLT (3/8-16X4-IN) | 1 | |
| 9N0869 | 57 WASHER-HARD (8.8X25.5X2-MM THK) | 4 | |
| 9S4190 | 58 PLUG-O-RING (7/8-14-THD) | 5 | |
| 9S8009 | 59 PLUG-O-RING | 4 | |
| 9S8752 | 60 NUT-FULL (3/8-16-THD) | 7 | |
| 9X6458 | 61 WASHER-HARD (10.2X22.5X3-MM THK) | 22 |
