System And Components
9Y-8930 AIR CLEANER GPS/N 4AR1-UP
Group No: 9Y-8930
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2515885 | 1 FILTER ELEMENT AS-AIR (PRIMARY)(AIR CLEANER) | 2 | |
| 9Y7663 | 2 FILTER ELEMENT AS-AIR (SECONDARY)(AIR CLEANER) | 2 | |
| 7W0444 | 3 NUT AS | 2 | |
| 3B4618 | 4 PIN-COTTER | 2 | |
| 1N8161 | 5 NUT-WING | 2 | |
| 5S4279 | 6 GASKET | 2 | |
| 7W0629 | 7 ADAPTER AS-FILTER | 2 | |
| 0066850 | 8 RETAINER (RING) | 2 | |
| 7E7376 | 9 BODY AS | 1 | |
| 2W9069 | 10 CUP AS-PRECLEANER | 3 | |
| 9M7959 | CLAMP-HOSE | 1 | |
| 1S5465 | GUARD-DUST | 1 | |
| 1953815 | SEAL | 1 | |
| 1S5485 | VALVE-DUST | 1 | |
| 5N7834 | 11 CLAMP AS | 3 | |
| 2M0879 | 12 SEAL-O-RING | 3 | |
| 7E7380 | 13 SHIELD (LH) | 1 | |
| 7E7378 | 14 SHIELD (RH) | 1 | |
| 1223196 | 15 FLANGE AS-AIR CLEANER | 2 | |
| 7W9857 | 16 GASKET | 2 | |
| 7E7377 | 17 GASKET | 2 | |
| 7E7379 | 18 SHIELD (FRONT) | 1 |
