System And Components
111-6118 BYPASS GP-EXHAUSTS/N 7TR1-215
Group No: 111-6118
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S7814 | 1 PLATE-RETAINER | 1 | |
| 7S7815 | 2 RETAINER-DIAPHRAGM | 1 | |
| 1131572 | 3 DIAPHRAGM | 1 | |
| 1P0659 | 4 WASHER (0.063-IN THK) | 1 | |
| 7S7816 | 5 LOCKNUT | 1 | |
| 1008019 | 6 BASE AS | 1 | |
| 7C9721 | 7 SCREW-MACHINE (1/4-20X2.5-IN) | 5 | |
| 2S4656 | 8 SHIM-SPRING (1.02-MM THK) | 2 | |
| 3B4504 | 9 LOCKWASHER | 5 | |
| 3S5849 | 10 GASKET | 2 | |
| 4W5224 | 11 VALVE | 1 | |
| 7E4677 | 12 SPRING (OUTER) | 1 | |
| 1116117 | 13 COVER | 1 | |
| 1116113 | 14 STOP-VALVE | 1 | |
| 3V3308 | 15 WASHER-HARD (10.2X20.5X2.5-MM THK) | 1 |
