System And Components
121-5800 BYPASS GP-EXHAUSTS/N 7TR3164-UP
Group No: 121-5800
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C9710 | 1 GASKET | 1 | |
| 3667441 | 2 BYPASS GP-EXHAUST | 1 | |
| 2N9288 | 3 STUD-TAPERLOCK (3/8-16X1.67-IN) | 4 | |
| 5M2894 | 4 WASHER-HARD (10.2X18.5X2.5-MM THK) | 5 | |
| 1687800 | 5 LOCKNUT (3/8-16-THD) | 4 | |
| 4H0553 | 6 FITTING (SPECIAL) | 1 | |
| 9G5127 | 7 BREATHER (ATMOSPHERIC AIR)(EXHAUST BYPASS) | 1 | |
| 2B0941 | 8 SPACER (10.5X19X19-MM THK) | 2 | |
| 3E3510 | 9 MANIFOLD | 1 | |
| 0903000 | 10 ELBOW-FLARED | 1 | |
| 5T9355 | 11 BRACKET | 1 | |
| 2M1908 | 12 FITTING-BULKHEAD | 1 | |
| 6V4362 | 13 CONNECTOR | 1 | |
| 4P7581 | 14 CLIP (LADDER) | 1 | |
| 4P0707 | 15 CLAMP AS | 2 | |
| 3078373 | GROMMET | 1 | |
| 0L1143 | 16 BOLT (3/8-16X2.5-IN) | 1 | |
| 0321267 | 17 CONNECTOR (STRAIGHT) | 1 | |
| 2R6806 | 18 CONNECTOR | 1 | |
| 3J1907 | 19 SEAL-O-RING | 5 | |
| 8T1890 | 20 CLIP (TAB) | 2 | |
| 0S0509 | 21 BOLT (3/8-16X0.75-IN) | 2 | |
| 7D1649 | 22 WASHER-HARD (13.5X32X5-MM THK) | 2 | |
| 0S1587 | 23 BOLT (1/2-13X1.75-IN) | 1 | |
| 1F7958 | 24 NUT-FULL (1/2-13-THD) | 1 | |
| 4J6302 | 26 TAG-IDENTIFICATION (NUMBER TWO) | 1 | |
| 9S8004 | 27 PLUG (9/16-18-THD) | 3 | |
| 1160118 | 28 CLIP | 1 | |
| 0T0065 | 29 BOLT (3/8-16X3.5-IN) | 2 | |
| 7K1181 | 30 STRAP-CABLE | 1 | |
| 8F2396 | 31 GROMMET | 1 | |
| 1094591 | 32 VALVE GP-SOLENOID (EXHAUST BYPASS) | 1 | |
| 1843231 | 33 HOSE AS | 1 | |
| 1215821 | 34 HOSE AS | 1 | |
| 8T1889 | 35 CLIP (SLOT) | 2 | |
| 7V6571 | 36 GROMMET | 2 |
