System And Components
126-9398 BYPASS GP-EXHAUSTS/N 7TR216-216
Group No: 126-9398
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7S7814 | 1 PLATE-RETAINER | 1 | |
| 7S7815 | 2 RETAINER-DIAPHRAGM | 1 | |
| 1131572 | 3 DIAPHRAGM | 1 | |
| 1P0659 | 4 WASHER (0.063-IN THK) | 1 | |
| 7S7816 | 5 LOCKNUT | 1 | |
| 1313963 | 6 BASE AS | 1 | |
| 7C9721 | 7 SCREW-MACHINE (1/4-20X2.5-IN) | 5 | |
| 2S4656 | 8 SHIM-SPRING (1.02-MM THK) | 2 | |
| 3B4504 | 9 LOCKWASHER | 5 | |
| 3S5849 | 10 GASKET | 2 | |
| 1313962 | 11 VALVE | 1 | |
| 1P0661 | 12 SPRING | 1 | |
| 1116117 | 13 COVER | 1 | |
| 1116113 | 14 STOP-VALVE | 1 | |
| 3V3308 | 15 WASHER-HARD (10.2X20.5X2.5-MM THK) | 1 | |
| 1P9897 | 16 SLEEVE | 1 | |
| 2S4655 | 17 SPRING | 1 |
