System And Components
298-5340 BYPASS GP-EXHAUSTS/N 7TR2070-3163
Group No: 298-5340
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1P0659 | 1 WASHER (0.063-IN THK) | 1 | |
| 1P0661 | 2 SPRING | 1 | |
| 1P9897 | 3 SLEEVE | 1 | |
| 2S4655 | 4 SPRING | 1 | |
| 2S4656 | 5 SHIM-SPRING (1.02-MM THK) | 2 | |
| 3B4504 | 6 LOCKWASHER | 5 | |
| 3S5849 | 7 GASKET | 2 | |
| 7S7814 | 8 PLATE-RETAINER | 1 | |
| 7S7815 | 9 RETAINER-DIAPHRAGM | 1 | |
| 7S7816 | 10 LOCKNUT | 1 | |
| 1116113 | 11 STOP-VALVE | 1 | |
| 1116117 | 12 COVER | 1 | |
| 1131572 | 13 DIAPHRAGM | 1 | |
| 1786393 | 14 SPACER (8-MM THK) | 1 | |
| 2576356 | 15 VALVE | 1 | |
| 2985339 | 16 BASE AS | 1 | |
| 7C9721 | 17 SCREW-MACHINE (1/4-20X2.5-IN) | 5 |
