System And Components
148-0834 CARTRIDGE GP-TURBOCHARGER -WATER COOLED BEARING HOUSINGS/N 7TR1-UP
Group No: 148-0834
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9Y3338 | 1 SHIELD (COMP SEAL) | 1 | |
| 2W1940 | 2 WASHER-RETAINING | 1 | |
| 9Y1676 | 3 RING (CARRIER SEAL) | 1 | |
| 3J1577 | 4 RING-RETAINING (INTERNAL) | 1 | |
| 9Y1677 | 5 COVER (THRUST BEARING) | 1 | |
| 6V6353 | 6 SEAL-O-RING | 1 | |
| 1220356 | 7 SHROUD-HEAT | 1 | |
| 9Y1679 | 8 BEARING (JOURNAL) | 2 | |
| 9Y2053 | 9 RING (SEAL) | 1 | |
| 1480835 | 10 SHAFT AS-TURBINE | 1 | |
| 9Y2051 | 11 BOLT AS | 2 | |
| 1220357 | 12 HOUSING-BEARING | 1 | |
| 9Y1683 | 13 RING (THRUST) | 1 | |
| 7E0360 | 14 BEARING (THRUST) | 1 | |
| 9Y1685 | 15 RING (FLINGER, THRUST) | 1 | |
| 9Y2052 | 16 RING (SEAL) | 1 | |
| 1141984 | 17 WHEEL-COMPRESSOR | 1 | |
| 2W1268 | 18 LOCKNUT (M14X1.5-THD) | 1 | |
| 6V5683 | 19 BOLT (M6X1X16-MM) | 3 | |
| 6A9204 | 20 LOCKWASHER | 3 | |
| 7B3028 | 21 SCREW-DRIVE (NO 4X 3/16-IN) | 4 | |
| 9Y1690 | 22 RETAINER (THRUST BEARING) | 1 | |
| 7W6534 | 23 PLUG-PIPE | 1 | |
| 7E2747 | KIT-REPAIR | 1 |
