System And Components
100-8080 LINES GP-AIR -INLET-INLETS/N 4AR1-UP
Group No: 100-8080
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E7788 | 1 ELBOW | 3 | |
| 9X3993 | 2 HOSE | 2 | |
| 6V4372 | 3 CLAMP-HOSE | 24 | |
| 1444144 | 4 ELBOW AS | 1 | |
| 7E7790 | 5 HOSE | 3 | |
| 8X3634 | 6 BRACKET AS | 1 | |
| 9R3845 | BOSS (M12X1.75X40-MM) | 1 | |
| 8X3635 | 7 STRIP | 6 | |
| 9X6605 | 8 U-BOLT | 6 | |
| 6V7744 | 9 LOCKNUT (M10X1.5-THD) | 12 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 20 | |
| 8T4136 | 11 BOLT (M10X1.5X25-MM) | 8 | |
| 8X4998 | 12 PLATE AS | 1 | |
| 9R3845 | BOSS (M12X1.75X40-MM) | 1 | |
| 0909019 | 13 PLUG-PIPE (1-11-1/2 NPT THD) | 1 | |
| 6I3348 | 15 TUBE AS | 1 | |
| 8X7889 | 16 PLATE | 1 | |
| 8X7857 | 17 BRACKET AS | 1 |
