Assembly
100%

155-0507 LINES GP-AIRS/N 7TR1-732; 7TR825-1203

Group No: 155-0507
Part NumberPart NameQty
7C79092 ELBOW (AIR INLET)14
7C79103 ELBOW (AIR INLET)2
7C81994 FLANGE16
7E23395 COVER2
10707636 PLATE AS2
1F0750NUT-WELD (3/8-16-THD)3
11962988 CLAMP AS4
7S7816LOCKNUT1
12369149 BAR2
123691510 PLATE1
133599811 ADAPTER2
152101212 ADAPTER2
152101313 ELBOW2
177906114 MANIFOLD1
0S050915 BOLT (3/8-16X0.75-IN)6
0S158816 BOLT (3/8-16X1.25-IN)10
0S159017 BOLT (3/8-16X2-IN)12
0S159118 BOLT (3/8-16X1.5-IN)32
103087319 GASKET2
141714020 PIPE2
141714221 COUPLING1
143362922 SEAL-O-RING6
158656323 SEAL-O-RING2
1A202924 BOLT (3/8-16X1.125-IN)9
1B436725 BOLT (5/8-11X3-IN)8
1T072026 BOLT-12 POINT HEAD (3/8-16X1.25-IN)64
1T076527 BOLT (3/8-16X1-IN)4
2A463928 BOLT (3/8-16X1.625-IN)32
3B191529 BOLT (3/8-16X1.375-IN)1
3S012730 BOLT-12 POINT HEAD (3/8-16X2.25-IN)44
4K036731 NUT-FULL (5/8-11-THD)8
4P664532 BRACKET1
4S589833 SEAL-O-RING16
5D954734 SPACER (1.15-IN THK)44
5M289435 WASHER-HARD (10.2X18.5X2.5-MM THK)152
5P824736 WASHER-HARD (17X32X3.5-MM THK)16
6B746937 SPACER (0.406X0.875X0.875-IN THK)4
6V383538 SEAL-O-RING2
6V391739 SEAL-O-RING12
6V505540 SEAL-O-RING2
6V510141 SEAL-O-RING16
6V510342 SEAL-O-RING4
7E234943 COUPLING2
7N508044 GASKET-MANIFOLD16
7W314545 PLATE4
8L278646 SEAL-O-RING2
8M317547 WASHER-HARD (10.2X16X3-MM THK)44
8T676248 PLUG-PIPE (1/2-14-THD)9
8T676549 PLUG-PIPE (1/4-18-THD)2
9S418550 PLUG (3/4-16-THD)2
9X400851 HOSE2
9X645852 WASHER-HARD (10.2X22.5X3-MM THK)6
