214-6019 LINES GP-AIRS/N 7TR1245-1394

Group No: 214-6019

Part Number	Part Name	Qty
1W2431	1 CLAMP-BAND	2
8T0193	NUT-FULL (5/16-24-THD)	1
7C7909	2 ELBOW (AIR INLET)	14
7C7910	3 ELBOW (AIR INLET)	2
7C8199	4 FLANGE	16
7N5080	5 GASKET-MANIFOLD	16
1070763	6 PLATE AS	2
1F0750	NUT-WELD (3/8-16-THD)	3
1153625	7 GROMMET	4
1196298	8 CLAMP AS	4
7S7816	LOCKNUT	1
1236914	9 BAR	2
1236915	10 PLATE	1
1521012	11 ADAPTER	2
1521013	12 ELBOW	2
1779061	13 MANIFOLD	1
1969138	14 GASKET	4
1969159	15 BELLOWS AS (STRAIGHT-AIR INLET)	1
2136557	16 BELLOWS AS (BENT-AIR INLET)	2
2102584	17 COVER	2
2H1190	PIN-DOWEL	2
0S0509	18 BOLT (3/8-16X0.75-IN)	6
0L2070	19 BOLT (3/8-16X2.25-IN)	20
0S1588	20 BOLT (3/8-16X1.25-IN)	10
0S1590	21 BOLT (3/8-16X2-IN)	8
0S1591	22 BOLT (3/8-16X1.5-IN)	32
1586563	23 SEAL-O-RING	2
1B4367	24 BOLT (5/8-11X3-IN)	8
1T0720	25 BOLT-12 POINT HEAD (3/8-16X1.25-IN)	64
1T0765	26 BOLT (3/8-16X1-IN)	24
2A4639	27 BOLT (3/8-16X1.625-IN)	32
3K0360	28 SEAL-O-RING	2
4K0367	29 NUT-FULL (5/8-11-THD)	8
4S5898	30 SEAL-O-RING	16
5M2894	31 WASHER-HARD (10.2X18.5X2.5-MM THK)	158
5P8247	32 WASHER-HARD (17X32X3.5-MM THK)	16
6V5055	33 SEAL-O-RING	2
6V5101	34 SEAL-O-RING	16
6V5103	35 SEAL-O-RING	4
7E2349	36 COUPLING	2
8T6758	37 PLUG-PIPE (1/4-18-THD)	2
8T6762	38 PLUG-PIPE (1/2-14-THD)	9
9S4185	39 PLUG (3/4-16-THD)	2
9X4008	40 HOSE	2
9X6458	41 WASHER-HARD (10.2X22.5X3-MM THK)	30
5K2232	42 SPACER (11-MM THK)	20
