System And Components
214-6019 LINES GP-AIRS/N 7TR1590-UP
Group No: 214-6019
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2431 | 1 CLAMP-BAND | 2 | |
| 7C7909 | 2 ELBOW (AIR INLET) | 14 | |
| 7C7910 | 3 ELBOW (AIR INLET) | 2 | |
| 7C8199 | 4 FLANGE | 16 | |
| 7N5080 | 5 GASKET-MANIFOLD | 16 | |
| 1070763 | 6 PLATE AS | 2 | |
| 1153625 | 7 GROMMET | 4 | |
| 2240808 | 8 CLAMP | 4 | |
| 1236914 | 9 BAR | 2 | |
| 1236915 | 10 PLATE | 1 | |
| 1521012 | 11 ADAPTER | 2 | |
| 1521013 | 12 ELBOW | 2 | |
| 1779061 | 13 MANIFOLD | 1 | |
| 1969138 | 14 GASKET | 4 | |
| 2071385 | 15 BELLOWS AS | 1 | |
| 3253656 | 16 BELLOWS AS | 2 | |
| 9X6458 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 18 | |
| 2350259 | 18 COVER AS-AFTERCOOLER | 2 | |
| 2H1190 | PIN-DOWEL | 1 | |
| 2350258 | COVER | 1 | |
| 0L2070 | 19 BOLT (3/8-16X2.25-IN) | 20 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1588 | 21 BOLT (3/8-16X1.25-IN) | 10 | |
| 0S1590 | 22 BOLT (3/8-16X2-IN) | 8 | |
| 0S1591 | 23 BOLT (3/8-16X1.5-IN) | 32 | |
| 9X4008 | 24 HOSE | 2 | |
| 1586563 | 25 SEAL-O-RING | 2 | |
| 1B4367 | 26 BOLT (5/8-11X3-IN) | 8 | |
| 1T0720 | 27 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 64 | |
| 1T0765 | 28 BOLT (3/8-16X1-IN) | 24 | |
| 2A4639 | 29 BOLT (3/8-16X1.625-IN) | 32 | |
| 3K0360 | 30 SEAL-O-RING | 2 | |
| 3V3308 | 31 WASHER-HARD (10.2X20.5X2.5-MM THK) | 12 | |
| 4K0367 | 32 NUT-FULL (5/8-11-THD) | 8 | |
| 4S5898 | 33 SEAL-O-RING | 16 | |
| 5M2894 | 34 WASHER-HARD (10.2X18.5X2.5-MM THK) | 158 | |
| 5P8247 | 35 WASHER-HARD (17X32X3.5-MM THK) | 16 | |
| 6V5055 | 36 SEAL-O-RING | 2 | |
| 6V5101 | 37 SEAL-O-RING | 16 | |
| 6V5103 | 38 SEAL-O-RING | 4 | |
| 7E2349 | 39 COUPLING | 2 | |
| 8T6758 | 40 PLUG-PIPE (1/4-18-THD) | 2 | |
| 8T6762 | 41 PLUG-PIPE (1/2-14-THD) | 9 | |
| 9S4185 | 42 PLUG (3/4-16-THD) | 2 |
