System And Components
451-8788 LINES GP-AIRS/N 7TR3563-UP
Group No: 451-8788
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7C7909 | 1 ELBOW (AIR INLET) | 14 | |
| 7C7910 | 2 ELBOW (AIR INLET) | 2 | |
| 7C8199 | 3 FLANGE | 16 | |
| 7E2346 | 4 ADAPTER | 2 | |
| 7E2349 | 5 COUPLING | 2 | |
| 7E2350 | 6 ADAPTER | 2 | |
| 7N5080 | 7 GASKET-MANIFOLD | 16 | |
| 9X4008 | 8 HOSE | 2 | |
| 1070763 | 9 PLATE AS | 4 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 3 | |
| 1153625 | 10 GROMMET | 4 | |
| 1236914 | 11 BAR | 2 | |
| 1236915 | 12 PLATE | 1 | |
| 1609848 | 13 ELBOW | 2 | |
| 1779061 | 14 MANIFOLD | 1 | |
| 1969138 | 15 GASKET | 4 | |
| 2071385 | 16 BELLOWS AS | 1 | |
| 2350259 | 17 COVER AS-AFTERCOOLER | 2 | |
| 2H1190 | PIN-DOWEL | 1 | |
| 2350258 | COVER | 1 | |
| 3253656 | 18 BELLOWS AS | 2 | |
| 0L2070 | 19 BOLT (3/8-16X2.25-IN) | 24 | |
| 0S0509 | 20 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1590 | 21 BOLT (3/8-16X2-IN) | 12 | |
| 1653929 | 22 BOLT (3/8-16X1.5-IN) | 42 | |
| 0S1595 | 23 BOLT (1/2-13X1.25-IN) | 4 | |
| 1C2251 | 24 BOLT (3/8-16X1.87-IN) | 6 | |
| 1T0720 | 25 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 64 | |
| 1T0765 | 26 BOLT (3/8-16X1-IN) | 24 | |
| 1W2431 | 27 CLAMP-BAND | 2 | |
| 2240808 | 28 CLAMP | 4 | |
| 2A4639 | 29 BOLT (3/8-16X1.625-IN) | 32 | |
| 2M0849 | 30 WASHER-HARD (13.5X25.5X5-MM THK) | 4 | |
| 3K0360 | 31 SEAL-O-RING | 2 | |
| 4S5898 | 32 SEAL-O-RING | 16 | |
| 5M2894 | 33 WASHER-HARD (10.2X18.5X2.5-MM THK) | 176 | |
| 5P8940 | 34 SEAL-O-RING | 4 | |
| 6D9157 | 35 SEAL-O-RING | 2 | |
| 6V1820 | 36 BOLT (M10X1.5X30-MM) | 8 | |
| 6V5101 | 37 SEAL-O-RING | 16 | |
| 6V5103 | 38 SEAL-O-RING | 4 | |
| 6V5839 | 39 WASHER (11X21X2.5-MM THK) | 8 | |
| 8T6758 | 40 PLUG-PIPE (1/4-18-THD) | 2 | |
| 8T6762 | 41 PLUG-PIPE (1/2-14-THD) | 8 | |
| 9S4185 | 42 PLUG (3/4-16-THD) | 2 | |
| 9S8752 | 43 NUT-FULL (3/8-16-THD) | 8 | |
| 9X6458 | 44 WASHER-HARD (10.2X22.5X3-MM THK) | 34 |
