9Y-8914 LINES GP-AIR -TURBOCHARGERS/N 7TR1-1203

Group No: 9Y-8914
Part NumberPart NameQty
0S05091 BOLT (3/8-16X0.75-IN)6
4J85362 CLAMP
4S58983 SEAL-O-RING16
6B74694 SPACER (0.406X0.875X0.875-IN THK)4
6V38355 SEAL-O-RING2
6V39176 SEAL-O-RING12
7C79097 ELBOW (AIR INLET)14
7C79108 ELBOW (AIR INLET)2
7C81999 FLANGE16
7E233910 COVER2
7E234611 ADAPTER2
7E235012 ADAPTER2
7E870613 MANIFOLD-INLET1
7N508014 GASKET-MANIFOLD16
7W314515 PLATE4
8T676216 PLUG-PIPE (1/2-14-THD)8
8T676517 PLUG-PIPE (1/4-18-THD)2
107076318 PLATE AS4
1F0750NUT-WELD (3/8-16-THD)3
113819419 CAP
115362520 GROMMET4
123691421 BAR2
123691522 PLATE1
133599823 ADAPTER2
143362924 SEAL-O-RING6
160984825 ELBOW2
0L207026 BOLT (3/8-16X2.25-IN)4
0S159027 BOLT (3/8-16X2-IN)16
0S159128 BOLT (3/8-16X1.5-IN)42
0S159529 BOLT (1/2-13X1.25-IN)4
103087330 GASKET2
141714031 PIPE2
141714232 COUPLING1
1A202933 BOLT (3/8-16X1.125-IN)9
1C225134 BOLT (3/8-16X1.87-IN)6
1T072035 BOLT-12 POINT HEAD (3/8-16X1.25-IN)64
1T076536 BOLT (3/8-16X1-IN)4
224080837 CLAMP4
2A463938 BOLT (3/8-16X1.625-IN)32
2M084939 WASHER-HARD (13.5X25.5X5-MM THK)4
3B191540 BOLT (3/8-16X1.375-IN)1
3S012741 BOLT-12 POINT HEAD (3/8-16X2.25-IN)44
4P664542 BRACKET1
5D954743 SPACER (1.15-IN THK)44
5M289444 WASHER-HARD (10.2X18.5X2.5-MM THK)170
5P894045 SEAL-O-RING4
6D915746 SEAL-O-RING2
6V182047 BOLT (M10X1.5X30-MM)8
6V510148 SEAL-O-RING16
6V510349 SEAL-O-RING4
6V583950 WASHER (11X21X2.5-MM THK)8
7E234951 COUPLING2
8M317552 WASHER-HARD (10.2X16X3-MM THK)44
8T676253 PLUG-PIPE (1/2-14-THD)1
9S875254 NUT-FULL (3/8-16-THD)8
9X400855 HOSE2
9X645856 WASHER-HARD (10.2X22.5X3-MM THK)10
