System And Components
394-1410 LINES GP-TURBOCHARGER AIRS/N 7TR3413-UP
Group No: 394-1410
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4P0707 | 1 CLAMP AS | 6 | |
| 3078373 | GROMMET | 1 | |
| 4P6645 | 2 BRACKET | 1 | |
| 3941404 | 3 HOSE & TUBE AS | 1 | |
| 3941406 | 4 HOSE & TUBE AS | 1 | |
| 3941407 | 5 HOSE & TUBE AS | 2 | |
| 3941409 | 6 HOSE & TUBE AS | 1 | |
| 3949066 | 7 HOSE & TUBE AS | 1 | |
| 0L1352 | 8 BOLT (3/8-16X3.25-IN) | 1 | |
| 0T0573 | 9 BOLT (3/8-16X2.75-IN) | 1 | |
| 1333260 | 10 SPACER (11X19X10-MM THK) | 1 | |
| 8U4791 | 11 WASHER (11X21X8-MM THK) | 1 | |
| 1623858 | 12 SPACER (12X19X33.5-MM THK) | 1 | |
| 0S1571 | 13 BOLT (3/8-16X1.75-IN) | 1 | |
| 2287090 | 14 SEAL-O-RING | 8 | |
| 2385080 | 15 SEAL-O-RING | 2 | |
| 2H5330 | 16 BOLT (3/8-16X2.88-IN) | 2 | |
| 3537957 | 17 GROMMET | 5 | |
| 6V8625 | 18 ELBOW | 2 | |
| 6V8731 | 19 UNION | 2 | |
| 8C7306 | 20 ADAPTER | 2 | |
| 8T1887 | 21 CLIP (SLOT) | 5 | |
| 8T1888 | 22 CLIP (TAB) | 5 | |
| 0S1608 | 23 BOLT (3/8-16X3.75-IN) | 1 | |
| 9S8752 | 24 NUT-FULL (3/8-16-THD) | 6 | |
| 9X6458 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 14 | |
| 1A5964 | 26 BOLT (3/8-16X4.5-IN) | 1 | |
| 7C6921 | 27 SPACER (11X20X22.8-MM THK) | 2 | |
| 7X3186 | 28 BOLT (3/8-16X2.125-IN) | 1 |
