System And Components
8X-2852 PIPE GP-EXHAUST -RH PLATFORMS/N 4AR1-UP
Group No: 8X-2852
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G7031 | 1 ELBOW | 1 | |
| 8T0375 | 2 BOLT (M16X2X45-MM) | 4 | |
| 7K1270 | WASHER (17X38X8-MM THK) | 4 | |
| 5P8247 | WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 8X3293 | 3 TUBE AS | 1 | |
| 8T4195 | 4 BOLT (M10X1.5X30-MM) | 8 | |
| 8T4121 | WASHER-HARD (11X21X2.5-MM THK) | 8 | |
| 8X3268 | 5 BRACKET AS | 1 | |
| 0925524 | 6 BOLT (M12X1.75X80-MM) | 2 | |
| 6V8149 | NUT (M12X1.75-THD) | 2 |
