System And Components
9Y-8888 PIPE GP-EXHAUST -RH-RH TURBOSS/N 4AR1-UP
Group No: 9Y-8888
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E8452 | 1 CLAMP | 2 | |
| 7E7861 | 2 ELBOW AS | 1 | |
| 7E7860 | 3 ELBOW AS | 1 | |
| 7E7858 | 4 PIPE AS | 1 | |
| 7E7859 | 5 ELBOW AS | 1 | |
| 6G7038 | 6 RING-SEAL | 2 | |
| 4P9979 | 7 BRACKET AS | 1 | |
| 4P9980 | 8 BRACKET AS | 1 | |
| 4P9981 | 9 STRAP AS | 1 | |
| 5G3845 | 10 BOSS (12.8X25X50-MM THK) | 2 | |
| 8T4172 | 11 BOLT (M10X1.5X80-MM) | 2 | |
| 7X7729 | WASHER (11X25X3-MM THK) | 2 | |
| 8T4183 | 12 BOLT (M12X1.75X40-MM) | 7 | |
| 5P1076 | WASHER-HARD (13.5X30X4-MM THK) | 14 | |
| 8T4244 | NUT (M12X1.75-THD) | 7 |
