System And Components
147-0790 TURBOCHARGER GP -LOW PRESSURES/N 7TR1-837
Group No: 147-0790
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1215814 | 1 SUPPORT-TURBOCHARGER | 1 | |
| 7E9150 | 2 ELBOW | 1 | |
| 9X8289 | 4 BOLT-12 POINT HEAD (M10X1.5X45-MM) | 16 | |
| 4P2005 | 5 SPACER (11X22X15.5-MM THK) | 20 | |
| 1A1460 | 6 BOLT (1/2-13X2-IN) | 8 | |
| 1F7958 | 7 NUT-FULL (1/2-13-THD) | 8 | |
| 5P8245 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 9X8285 | 9 BOLT-HIGH TEMPERATURE (5/8-11X3.5-IN) | 8 | |
| 3H5954 | 10 BOLT (3/8-16X2-IN) | 16 | |
| 4P2007 | 11 SPACER (17X32X11.5-MM THK) | 8 | |
| 6V4605 | 12 LOCKNUT (5/8-11-THD) | 8 | |
| 5P7128 | 13 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 20 | |
| 1417161 | 14 BELLOWS AS | 2 | |
| 4P4865 | 15 FLANGE | 2 | |
| 1054322 | 16 COUPLING | 1 | |
| 7L0520 | 17 STUD-TAPERLOCK (3/8-16X1.968-IN) | 8 | |
| 1215813 | 18 ELBOW-EXHAUST | 1 | |
| 8C8491 | 19 WASHER-HARD (10.2X22X3-MM THK) | 48 | |
| 1215812 | 20 HOUSING-BYPASS | 1 | |
| 1687800 | 21 LOCKNUT (3/8-16-THD) | 32 | |
| 1234874 | 22 TURBOCHARGER GP (LOW PRESS) | 2 | |
| 4P2006 | 23 SPACER (5-MM THK) | 8 | |
| 7E8452 | 24 CLAMP | 1 | |
| 1586601 | 26 COUPLING | 2 | |
| 1382305 | 27 TURBOCHARGER GP (HIGH PRESSURE) | 2 | |
| 1566231 | 32 BLOCK | 4 | |
| 6V4249 | 33 BOLT (M10X1.5X50-MM) | 8 | |
| 3E4353 | 34 WASHER-HARD (11X25X3-MM THK) | 8 |
