System And Components
155-0504 TURBOCHARGER GP -HIGH ALTITUDES/N 7TR1202-1307
Group No: 155-0504
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3H5954 | 1 BOLT (3/8-16X2-IN) | 16 | |
| 5P7128 | 2 BOLT-HIGH TEMPERATURE (3/8-16X2-IN) | 8 | |
| 6V1525 | 3 STUD-TAPERLOCK (3/8-16X2.16-IN) | 4 | |
| 7L0520 | 4 STUD-TAPERLOCK (3/8-16X1.968-IN) | 4 | |
| 8M3175 | 5 WASHER-HARD (10.2X16X3-MM THK) | 12 | |
| 9X8882 | 6 BOLT (5/8-11X2.5-IN) | 2 | |
| 1215812 | 7 HOUSING-BYPASS | 1 | |
| 1215813 | 8 ELBOW-EXHAUST | 1 | |
| 1417161 | 9 BELLOWS AS | 2 | |
| 1521011 | 10 ELBOW | 1 | |
| 1521015 | 11 ADAPTER | 1 | |
| 1537502 | 12 COUPLING | 2 | |
| 1537504 | 13 COUPLING | 2 | |
| 1783654 | 14 TURBOCHARGER GP (HIGH PRESSURE) | 2 | |
| 1499284 | 15 TURBOCHARGER GP (LOW PRESSURE) | 2 | |
| 1054322 | 16 COUPLING | 1 | |
| 1A1460 | 17 BOLT (1/2-13X2-IN) | 8 | |
| 1D4586 | 18 BOLT (5/8-11X3.5-IN) | 4 | |
| 1F7958 | 19 NUT-FULL (1/2-13-THD) | 8 | |
| 2N2766 | 20 LOCKNUT (3/8-16-THD) | 32 | |
| 4D0242 | 21 BOLT-SOCKET HEAD (5/8-11X3-IN) | 8 | |
| 2213854 | 22 BOLT-12 POINT HEAD (3/8-16X1.375-IN) | 12 | |
| 4K0367 | 23 NUT-FULL (5/8-11-THD) | 14 | |
| 4P4865 | 24 FLANGE | 2 | |
| 5P8245 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 5P8247 | 26 WASHER-HARD (17X32X3.5-MM THK) | 22 | |
| 7E8452 | 27 CLAMP | 1 | |
| 8C8491 | 28 WASHER-HARD (10.2X22X3-MM THK) | 72 | |
| 9X8289 | 29 BOLT-12 POINT HEAD (M10X1.5X45-MM) | 24 | |
| 9X8881 | 30 BOLT (5/8-11X2.25-IN) | 2 |
