System And Components
233-4742 CYLINDER BLOCK GPS/N 5HK30746-UP
Group No: 233-4742
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1138 | 1 BOLT (3/8-24X0.5-IN) | 4 | |
| 3434295 | 2 PLUG | 6 | |
| 6I0164 | 3 LINER | 4 | |
| 6I0219 | 4 PLATE | 1 | |
| 6I0220 | 5 GASKET | 1 | |
| 6I0298 | 6 GASKET | 1 | |
| 6I0302 | 7 BOLT (M10X1.5X25-MM) | 4 | |
| 6I0363 | 8 BOLT (M6X1X20-MM) | 2 | |
| 6I0572 | 9 BOLT (M8X1.25X20-MM) | 2 | |
| 3024757 | 10 PLUG | 1 | |
| 9Y5015 | 11 PLUG-FREEZE | 1 | |
| 0S2353 | 12 BOLT (5/8-18X3.75-IN) | 10 | |
| 0365802 | 13 BEARING | 1 | |
| 0676002 | 14 DOWEL | 10 | |
| 0676006 | 15 PLUG | 2 | |
| 0676043 | 16 PLUG-SIDE | 6 | |
| 0676805 | 17 PLUG | 1 | |
| 0676808 | 18 PLUG | 1 | |
| 0679520 | 19 SPACER | 4 | |
| 0691124 | 20 PLUG | 1 | |
| 1013923 | 21 PLATE | 1 | |
| 1279768 | 22 PLUG | 1 | |
| 1471978 | 23 DOWEL | 2 | |
| 1619820 | 24 PIN | 2 | |
| 2490207 | 25 BRIDGE | 1 | |
| 2141668 | 26 WASHER-SPECIAL | 1 | |
| 2152103 | 27 PLUG | 4 | |
| 6I1074 | 28 VALVE AS (OIL JET) | 4 | |
| 6I0686 | 28A SPRING | 1 | |
| 5B9318 | 28B BALL | 1 | |
| 6I1076 | 28C RETAINER | 1 | |
| 1483026 | 29 JET AS-PISTON COOLING | 4 |
