System And Components
115-1158 LINES GP-ENGINE OILS/N 5HK30746-99999
Group No: 115-1158
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P8245 | 1 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 6I0631 | 2 BOLT (M6X1X12-MM) | 1 | |
| 6I0650 | 3 BOLT (M10X1.5X65-MM) | 1 | |
| 6I0785 | 4 HOUSING AS | 1 | |
| 6I0786 | 5 SPRING | 1 | |
| 6I0787 | 6 RING-RETAINING | 1 | |
| 7W4648 | 7 SEAT-SPRING | 1 | |
| 7W4782 | 8 PLUNGER | 1 | |
| 1013415 | 9 BOLT | 3 | |
| 8N7998 | 10 DOWEL | 1 | |
| 6I0918 | 11 NUT | 2 | |
| 6I3812 | 12 BOLT (M8X1.25X16-MM) | 1 | |
| 0676213 | 13 GASKET | 1 | |
| 6I1090 | 14 BOLT (M8X1.25X40-MM) | 2 | |
| 1068912 | 15 TUBE | 1 | |
| 1068913 | 16 BRACKET | 1 | |
| 1068914 | 17 PLATE | 1 | |
| 1068915 | 18 CLIP | 1 | |
| 1068916 | 19 BOLT (M6X16-MM) | 1 |
