System And Components
128-5862 CONTROL GP-GOVERNORS/N 2WM500-UP
Group No: 128-5862
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4200 | 1 BOLT (M8X1.25X16-MM) | 5 | |
| 8T4224 | 2 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 5P9085 | 3 CLIP | 1 | |
| 1172949 | 4 BRACKET AS | 1 | |
| 4I5399 | 5 GROMMET | 1 | |
| 4D7794 | 6 CLIP | 2 | |
| 0932065 | 7 GROMMET | 2 | |
| 9X8256 | 8 WASHER (6.6X12X2-MM THK) | 10 | |
| 8T6411 | 9 SCREW-MACHINE (M6X1X12-MM) | 4 | |
| 1327763 | 10 CONTROL AS | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 6 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 7 | |
| 9G3670 | HOUSING-PLUG | 1 | |
| 9G3677 | HOUSING-RECEPTACLE | 1 | |
| 1643187 | 11 PLATE | 1 | |
| 8T4134 | 12 NUT (M6X1-THD) | 1 | |
| 3W6485 | 13 SPRING | 1 | |
| 1285863 | 14 MOTOR AS-GOVERNOR | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 3 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 3 | |
| 9G3671 | HOUSING AS-CONNECTOR | 1 | |
| 1028034 | 15 RUBBER | 3 | |
| 7Y9390 | 16 KNOB | 1 | |
| 0965486 | 17 SCREW-MACHINE (M6X1X25-MM)(M6X1M25MM) | 3 | |
| 5C2890 | 18 NUT (M6X1-THD) | 1 | |
| 8T4138 | 19 BOLT (M6X1X20-MM) | 1 | |
| 1393951 | 20 STRIP | 1 |
