Assembly
100%

112-6518 LINES GP-FUELS/N 2WM500-UP

Group No: 112-6518
Part NumberPart NameQty
5C72611 NUT (M8X1.25-THD)2
09509602 CLAMP-HOSE6
6S10663 GROMMET1
09320684 GROMMET2
7K11815 STRAP-CABLE2
8T24366 HOSE (300CM)
8T42247 WASHER-HARD (8.8X16X2-MM THK)3
09658638 GROMMET1
9M84069 CLIP3
8T420010 BOLT (M8X1.25X16-MM)1
5K845111 CLIP1
093206512 GROMMET1
8T243613 HOSE (120CM)
8T243614 HOSE (140CM)
120484215 PIPE1
8T413316 NUT (M10X1.5-THD)1
8T412117 WASHER-HARD (11X21X2.5-MM THK)3
101392518 SEPARATOR GP-WATER1
032810019 WASHER (0.531X0.718X0.064-IN THK)2
033784920 PLUG2
8T413621 BOLT (M10X1.5X25-MM)2
125347722 PIPE2
125347823 PIPE1
4H249424 SLEEVE-FITTING2
067700125 NUT-SPECIAL2
