134-2216 HOOD & GUARD GPS/N 2WM500-UP

Group No: 134-2216
Part NumberPart NameQty
11611431 SHEET1
11607792 SUPPORT AS1
11903133 SHEET1
10303014 SHEET1
11445805 CHANNEL AS1
11557676 SHEET AS1
11557697 SHEET AS1
11677978 HOOD AS1
4I7924WASHER (4.5X40X1.2-MM THK)7
5P5934SEAL (.37M)
6P2216CAP7
1170425LINER1
1170427LINER1
11551909 CHANNEL AS1
119204210 SHEET AS1
1192040LINER1
131785711 SHEET AS1
6P2216CAP4
116027912 SUPPORT AS1
116077513 SUPPORT AS1
119031014 DOOR GP-ACCESS (HOOD)1
114457815 SHEET AS1
119031116 DOOR GP-ACCESS (HOOD)1
115518617 SUPPORT AS1
103031118 SUPPORT AS1
103032119 SUPPORT AS1
131785620 SHEET AS1
117386821 SHEET AS1
131785122 SHEET1
119203523 STAY1
4I011724 LATCH AS1
087390825 SHIM (1-MM THK)2
087390926 SHIM (2-MM THK)2
103031027 PLATE2
9X825628 WASHER (6.6X12X2-MM THK)8
8T413829 BOLT (M6X1X20-MM)8
096068430 SHIM (0.8-MM THK)4
102568931 SHIM (2-MM THK)4
8T422332 WASHER-HARD (13.5X25.5X3-MM THK)6
096378133 PIN-CLEVIS2
3B461834 PIN-COTTER2
8T422435 WASHER-HARD (8.8X16X2-MM THK)4
8T420036 BOLT (M8X1.25X16-MM)4
122701737 GROMMET (100MM OD 70MM ID)1
4I011838 HOOK AS1
102567339 ROD2
099142640 SPACER (19X32X2-MM THK)3
5C289041 NUT (M6X1-THD)4
102508042 STRIP2
5C955343 BOLT (M6X1X16-MM)4
8T026944 BOLT-SOCKET HEAD (M6X1X20-MM)4
6I603345 STOP2
4I801946 SUPPORT2
5P411547 WASHER-HARD (7.2X19X2-MM THK)8
8T413948 BOLT (M12X1.75X30-MM)8
5P107649 WASHER-HARD (13.5X30X4-MM THK)73
8T419250 BOLT (M12X1.75X25-MM)71
8T412151 WASHER-HARD (11X21X2.5-MM THK)2
4I843652 LOCK AS2
4I843853 SCREW-MACHINE (M6X1-THD)8
099641854 NUT (M6X1-THD)8
