128-5868 CONSOLE GP-OPERATOR -RHS/N 2WM500-UP

Group No: 128-5868
Part NumberPart NameQty
7Y31731 SCREW-BUTTON HEAD (M4X0.7X12-MM)19
13022592 PANEL AS1
12858693 PANEL1
7Y30364 LEVER1
11463285 FILM-INSTRUCTION1
7Y30946 SUPPORT AS1
6V9632NUT-WELD (M6X1-THD)2
7Y3270NUT (M4X0.7-THD)4
8T2321NUT-WELD (M8X1.25-THD)4
13023007 SUPPORT AS1
6V9632NUT-WELD (M6X1-THD)2
9G9155CLIP2
9X20448 SCREW-TRUSS HEAD (M6X1X16-MM)12
7Y30209 COVER1
8T420010 BOLT (M8X1.25X16-MM)4
8T422411 WASHER-HARD (8.8X16X2-MM THK)4
096390912 ADJUSTER2
096488313 LOCKNUT (M10X1.5-THD)1
8T412114 WASHER-HARD (11X21X2.5-MM THK)1
7Y308215 LEVER AS1
4H352116 SPRING1
6V982417 RING-RETAINING1
8C311118 ROD END2
7Y313319 ROD1
5C289020 NUT (M6X1-THD)2
9X825621 WASHER (6.6X12X2-MM THK)2
5C955322 BOLT (M6X1X16-MM)1
4I008723 FILM-INSTRUCTION1
4I008824 FILM-SLIDE LOCK1
4I042025 STRIP1
130253926 SHEET AS1
6V9632NUT-WELD (M6X1-THD)2
4I110027 COVER1
7Y316828 PLATE1
6V521029 SCREW-MACHINE (M4X0.7X10-MM)2
100770930 COVER1
7Y315531 COVER1
7Y316532 COVER AS1
7Y315433 COVER1
7Y315634 COVER-FRONT1
7Y319135 PANEL1
7Y326836 COVER1
7Y318437 KNOB1
7Y318538 KNOB1
7Y324839 SCREW (M4X0.7X12-MM)2
125730140 BRACKET AS2
7Y327241 SPACER (10.4X16X1.5-MM THK)4
7Y328242 WASHER (1.6-MM THK)4
7Y327143 SPACER (6.83X10.29X7-MM THK)4
8F132644 WASHER (4.2X9.5X0.8-MM THK)7
4I128245 GRIP1
7Y739446 SCREW-BUTTON HEAD (M8X1.25X25-MM)2
093208747 GROMMET1
7Y328148 GROMMET1
