System And Components
126-3537 TANK GP-HYDRAULICS/N 1NB1390-UP
Group No: 126-3537
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G9034 | 2 COVER | 1 | |
| 1J8595 | 3 GASKET | 1 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 76 | |
| 2K4973 | 5 LOCKNUT (3/8-16-THD) | 77 | |
| 5T0093 | 6 HOSE | 1 | |
| 5P1717 | 7 CLAMP-HOSE | 4 | |
| 1925125 | 8 ELBOW | 1 | |
| 2H6338 | 9 SEAL-O-RING | 3 | |
| 5K7143 | 10 BOLT-SELF-LOCKING (1/2-13X1.5-IN) | 8 | |
| 5P8245 | 11 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 6G9988 | 12 ELBOW | 1 | |
| 8L8137 | 13 CLIP | 1 | |
| 5K9107 | 14 BOLT-LOCKING (3/8-16X0.75-IN) | 1 | |
| 9S1366 | 15 BOLT (1/2-13X2.5-IN) | 2 | |
| 1263584 | 16 TUBE AS | 1 | |
| 7F8268 | 17 SEAL-O-RING | 1 | |
| 4P0519 | 18 ADAPTER AS-DRAIN | 1 | |
| 1095840 | ADAPTER-PLUG | 1 | |
| 1095839 | PLUG-DRAIN (HYDRAULIC OIL) | 1 | |
| 3B0551 | 19 PLUG-PIPE | 1 | |
| 6V3830 | 20 SEAL-O-RING | 1 | |
| 2G9354 | 21 COVER AS (HYDRAULIC OIL) | 1 | |
| 5D4218 | BLOCK | 1 | |
| 2G9356 | 22 GASKET | 1 | |
| 5T0096 | 23 SCREEN AS (HYDRAULIC OIL) | 1 | |
| 0307335 | 24 BOLT-LOCKING (5/8-11X1.5-IN) | 4 | |
| 5P8247 | 25 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 6G9765 | 26 TUBE AS | 1 | |
| 5T4617 | 27 COVER AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 6C3680 | RIVET-POP | 8 | |
| 5H8985 | 28 PIN-SPRING | 1 | |
| 5D0353 | 29 BOLT-LOCKING (3/8-16X1-IN) | 4 | |
| 5M2894 | 30 WASHER-HARD (10.2X18.5X2.5-MM THK) | 13 | |
| 4D6082 | 31 BOLT (1/2-13X1.5-IN) | 1 | |
| 0T0883 | 32 WASHER (0.531X1X0.065-IN THK) | 1 | |
| 3B4610 | 33 PIN-COTTER | 1 | |
| 5T4624 | 34 MOUNTING | 1 | |
| 6N8863 | 35 WASHER (10.2X32X2.5-MM THK) | 3 | |
| 0L2070 | 36 BOLT (3/8-16X2.25-IN) | 1 | |
| 3G7233 | 37 FILTER GP-OIL (HYDRAULIC) | 1 | |
| 6G1249 | 38 GASKET | 1 | |
| 0310219 | 39 BOLT-LOCKING (3/8-16X1.75-IN) | 8 | |
| 3D6678 | 40 STRAINER (METAL)(HYDRAULIC OIL) | 1 | |
| 5D1901 | 41 WASHER (106.5X126.5X2.5-MM THK) | 1 | |
| 1M8649 | 42 RING-RETAINING | 1 | |
| 7B2805 | 43 RING-LOCK | 1 | |
| 4J3815 | 44 GASKET | 1 | |
| 4J3816 | 45 PLATE | 1 | |
| 1L5072 | 46 DOWEL | 1 | |
| 9M7394 | 47 LEVER | 1 | |
| 8T2275 | 48 BALL | 1 | |
| 5D1902 | 49 COVER-HYDRAULIC CAP | 1 | |
| 4J3754 | 50 CAP-FILLER (HYDRAULIC OIL) | 1 | |
| 9J8243 | 51 RETAINER | 1 | |
| 6J1080 | 52 GROMMET | 1 | |
| 0352017 | 53 SCREW-BUTTON HEAD (3/8-16X1-IN) | 4 | |
| 6J1081 | 54 GLASS-SIGHT (HYDRAULIC LEVEL) | 1 | |
| 5H6005 | 55 SEAL-O-RING | 4 | |
| 6J1126 | 56 PLATE-INDICATOR | 1 | |
| 1742289 | 59 TANK AS-HYDRAULIC | 1 |
