System And Components
7N8974 DRIVE GP-FANREFER TO 4N6973 RADIATOR CHART-PAGE 176
Group No: 7N8974
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1D4566 | 1 BOLT | 2 | |
| 1F7960 | 2 WASHER | 4 | |
| 4N2372 | 3 ADAPTER-BRACKET | 1 | |
| 8L5213 | 4 BOLT | 1 | |
| 1D4719 | 5 NUT | 2 | |
| 5S2106 | 6 SEAL-LIP TYPE | 1 | |
| 8H9789 | 7 BALL BEARING | 1 | |
| 7N8828 | 8 PULLEY-FAN | 1 | |
| 7N8827 | 9 HUB | 1 | |
| 5S7264 | 10 WASHER-RETAINING 42.93MM(1.69IN)OD | 1 | |
| 7N2900 | WASHER-RETAINING 47.63MM(1.88IN)OD | 1 | |
| 1H5403 | 11 BOLT 50.8MM(2IN)LONG | 2 | |
| 5P7979 | BOLT-SELF LOCKING 57.15MM(2.25IN)LONG | 2 | |
| 1B5174 | 12 PLUG-PIPE | 1 | |
| 4N2371 | 13 ADAPTER-FAN | 1 | |
| 3L1425 | 14 BALL BEARING | 1 | |
| 9F4446 | 15 SEAL-O-RING | 1 | |
| 4N6373 | 16 V-BELT SET | 1 | |
| 0L2070 | 17 BOLT | 6 | |
| 2P2243 | 18 SPACER | 1 | |
| 6N7688 | 19 BRACKET AS-FAN | 1 | |
| 4N0684 | 20 PIN-DOWEL | 1 | |
| 5S9062 | 21 SPACER | 1 | |
| 4B4550 | 22 FITTING-RELIEF | 1 | |
| 2P9084 | 23 STUD-TAPERLOCK | 2 | |
| 1A2029 | 24 BOLT | 2 | |
| 9N5120 | 25 BRACKET-ADJUSTABLE | 1 | |
| 2D4867 | 26 FITTING-HYDRAULIC | 1 |
