System And Components
8N2361 CARTRIDGE GP-TURBOCHARGER*RPART OF 7W7125 TURBOCHARGER
Group No: 8N2361
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S4484 | 1 LOCKNUT-TURBOCHARGER | 1 | |
| 8N2363 | 2 WHEEL-COMPRESSOR | 1 | |
| 9M8919 | 3 RING-SEAL | 2 | |
| 1P1120 | 4 RING-SEAL | 1 | |
| 8N0819 | 5 BACKPLATE AS | 1 | |
| 9M8911 | 6 COLLAR-THRUST | 1 | |
| 7N3760 | 7 SHROUD-TURBINE WHEEL | 1 | |
| 6N6611 | 8 SHAFT & WHEEL AS | 1 | |
| 7N3759 | 9 RING-PISTON | 1 | |
| 9M8915 | 10 RING-RETAINING | 3 | |
| 9N2035 | 11 HOUSING AS-CENTER | 1 | |
| 4M6646 | PIN-GROOVE | 2 | |
| 7W2368 | RING-SEAL | 1 | |
| 6N5004 | 12 BEARING-THRUST | 1 | |
| 0S1616 | 13 BOLT | 4 | |
| 9N2036 | PLATE-LOCK | 4 | |
| 9N2046 | 14 SPACER-THRUST | 1 | |
| 9N2041 | 15 KIT-BEARING | 1 | |
| 7N3193 | KIT-BEARING | 1 | |
| 7N3194 | KIT-BEARING | 1 | |
| 9N2047 | NAMEPLATE-CARTRIDGE | 1 | |
| 2F0808 | SCREW | 2 |
