System And Components
8I-1511 LINES GP-FUELPART OF 8I-1501 SCRAPER AR
Group No: 8I-1511
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1251211 | 1 HOSE AS (FUEL RETURN) | 1 | |
| 6V8981 | 2 ELBOW | 1 | |
| 6V8983 | 3 ELBOW | 1 | |
| 1S0994 | 4 CLIP | 10 | |
| 1251213 | 5 HOSE AS (FUEL SUPPLY) | 1 | |
| 6V1889 | 6 CLIP | 10 | |
| 6V9169 | 7 NUT (13/16-16-THD) | 2 | |
| 1251215 | 8 PLATE | 1 | |
| 8T7529 | 9 CLIP | 2 | |
| 2P1293 | 10 LOCKNUT (1-3/16-12-THD) | 2 | |
| 6V8995 | 11 UNION (STRAIGHT) | 1 | |
| 6V8997 | 12 UNION | 1 | |
| 1251217 | 13 SUPPORT AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 6V8398 | 14 SEAL-O-RING | 5 | |
| 6V8625 | 15 ELBOW | 1 | |
| 3D2824 | 16 SEAL-O-RING | 3 | |
| 8I1516 | 17 HOSE AS | 1 | |
| 8I1517 | 18 HOSE AS | 1 | |
| 6V8637 | 19 CONNECTOR | 1 | |
| 5M3062 | 20 BOLT (3/8-16X0.75-IN) | 11 | |
| 3K0360 | 21 SEAL-O-RING | 1 | |
| 6V8358 | 22 VALVE-BALL (MANUAL SHUTOFF) | 1 | |
| 5P1075 | 23 WASHER-HARD (10.2X22.5X3-MM THK) | 11 | |
| 6V9746 | 24 SEAL-O-RING | 5 | |
| 8T3491 | 25 ELBOW | 1 |
