System And Components
5T-0650 CONTROL GP-STEERINGS/N 2PS1-UP
Group No: 5T-0650
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6G8364 | 1 PLATE AS | 1 | |
| 5T4795 | 2 COVER | 1 | |
| 4L6454 | 3 BOLT (3/8-16X1-IN) | 8 | |
| 8T4896 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6G7784 | 4 PLATE | 1 | |
| 6V3884 | 5 SCREW-HEX SOCKET (1/4-20X0.5-IN) | 5 | |
| 5P2424 | 6 BOLT (1/2-13X2.25-IN) | 2 | |
| 8T4223 | 7 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 5T0700 | 8 UNIVERSAL JOINT GP-STEERING | 1 | |
| 2K4821 | 9 LOCKNUT (5/8-18-THD) | 1 | |
| 8T4122 | WASHER-HARD (17X32X3.5-MM THK) | 1 | |
| 1185438 | 10 WHEEL | 1 | |
| 8R2916 | 11 COVER AS (CAT STEERING WHEEL) | 1 | |
| 5T7815 | 12 SHAFT-STEERING | 1 | |
| 6G7828 | 13 SUPPORT | 1 | |
| 6G7818 | PLUNGER | 1 | |
| 5T6153 | SHIM | ||
| 5T4447 | 14 GRIP | 1 | |
| 5T0454 | 15 HANDLE AS | 1 | |
| 1D5874 | SPACER (0.766X1.25X1.125-IN THK) | 1 | |
| 6G7587 | 16 SUPPORT | 1 | |
| 9B7237 | 17 BOLT (3/8-16X1.25-IN) | 1 | |
| 4N0205 | SPACER (0.42X0.75X0.6-IN THK) | 1 | |
| 6G8351 | 18 LEVER | 1 | |
| 8X8457 | 19 SPRING | 1 | |
| 1J4384 | 20 PIN-CLEVIS | 1 | |
| 3B4617 | PIN-COTTER | 1 | |
| 7X0326 | 21 BOLT (1/2-13X3-IN) | 4 | |
| 6G7473 | 22 SUPPORT | 1 | |
| 8X7242 | 23 BEARING | 1 | |
| 8T0762 | RING-RETAINING | 1 | |
| 8W0006 | SEAL | 1 | |
| 5T0455 | 24 COLUMN AS | 1 | |
| 5B1983 | 25 BOSS (3/8-16-THD) | 2 | |
| 4F5932 | 26 STOP | 1 | |
| 3K5359 | 27 LUG | 1 | |
| 5T0448 | 28 CABLE AS | 1 | |
| 5T0446 | 29 PULLEY | 1 | |
| 8H4320 | 30 BALL BEARING | 2 | |
| 6G0009 | 31 BRACKET | 2 | |
| 0310215 | 32 BOLT-LOCKING (1/4-20X0.625-IN) | 3 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 2B5886 | 33 BUSHING | 1 | |
| 3B5301 | 34 PIN-COTTER | 1 | |
| 2K7979 | 35 BUSHING | 2 | |
| 6F9254 | 36 WASHER-THRUST | 2 | |
| 4L9337 | 37 BOLT (3/8-16X1.5-IN) | 1 | |
| 8T4896 | 38 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 6G8352 | 39 SPRING | 1 | |
| 3P9029 | 40 KEY | 1 | |
| 1101310 | 41 SEAL | 1 | |
| 9D3868 | 42 SCREW (BUTTON HEAD) | 4 | |
| 6G7802 | 43 PLATE | 1 | |
| 8T2502 | 44 BOLT (3/8-16X1.125-IN) | 7 | |
| 6K8162 | 45 RING-RETAINING | 1 | |
| 5H6480 | 46 RING-RETAINING | 1 | |
| 6V3812 | 47 BEARING AS-BALL | 1 | |
| 5M6213 | 48 PLUG-PIPE (1/4-18-THD) | 2 |
