System And Components
117-9512 CYLINDER BLOCK ASS/N 81Z18887-99999
Group No: 117-9512
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1102220 | 1 SEAL-LINER | 12 | |
| 1427072 | 2 SEAL-LINER | 12 | |
| 1426217 | 3 SEAL-O-RING | 12 | |
| 1979322 | 4 LINER-CYLINDER BLOCK | 12 | |
| 9L5854 | 5 BAND-FILLER (130.2-MM ID) | 12 | |
| 3P1323 | 6 BOLT-BEARING CAP (7/8-14X7.75-IN) | 14 | |
| 9H1031 | WASHER-HARD (24X41.5X6-MM THK) | 14 | |
| 4851966 | 7 CAP-CRANKSHAFT | 7 | |
| 4N6658 | 8 BUSHING (1.3-IN WIDE) | 2 | |
| 7W6492 | 9 PLUG-PIPE (1/2-14-THD) | 2 | |
| 4N0685 | 10 BUSHING (1-IN WIDE) | 5 | |
| 4W4588 | SLEEVE-LIFTER BORE | ||
| 4W6061 | SLEEVE | ||
| 2W3815 | INSERT-LINER SEAT (1.605-MM THK) | ||
| 6I4363 | INSERT-LINER SEAT (1.555-MM THK) | ||
| 6I4364 | INSERT-LINER SEAT (1.655-MM THK) | ||
| 5N0093 | INSERT-LINER SEAT (2.71-MM THK) | ||
| 6I4365 | INSERT-LINER SEAT (2.66-MM THK) | ||
| 6I4366 | INSERT-LINER SEAT (2.76-MM THK) | ||
| 9Y3368 | INSERT-LINER SEAT (0.822-MM THK) | ||
| 6I4361 | INSERT-LINER SEAT (0.772-MM THK) | ||
| 6I4362 | INSERT-LINER SEAT (0.872-MM THK) | ||
| 1010524 | INSERT-LINER SEAT (5.16-MM THK) | ||
| 1010523 | INSERT-LINER SEAT (5.21-MM THK) | ||
| 1010525 | INSERT-LINER SEAT (5.26-MM THK) |
