Assembly
100%

129-6631 LINES GP-AIRS/N 81Z18887-25561

Group No: 129-6631
Part NumberPart NameQty
12284321 ELBOW-EXHAUST1
12284332 ELBOW-EXHAUST1
8N08793 CLAMP4
6I28554 TUBE AS1
13322325 TUBE AS1
6N71528 SUPPORT-ELBOW1
6N71499 SUPPORT-ELBOW1
3N336810 PIPE-EXHAUST1
1W751511 COUPLING2
1A518312 BOLT (3/8-16X4.75-IN)3
4N184913 TUBE-AIR2
5P570014 SEAL-O-RING8
4N852315 PIPE-OUTLET (LH)1
4N867716 PIPE-OUTLET (RH)1
0S158717 BOLT (1/2-13X1.75-IN)4
0S159118 BOLT (3/8-16X1.5-IN)4
2M841119 STUD-TAPERLOCK1
9S875220 NUT-FULL (3/8-16-THD)3
1A202921 BOLT (3/8-16X1.125-IN)2
0S160822 BOLT (3/8-16X3.75-IN)2
0L114323 BOLT (3/8-16X2.5-IN)6
9F899924 BOLT (3/8-16X7-IN)1
0S161925 BOLT (3/8-16X3-IN)4
3B191526 BOLT (3/8-16X1.375-IN)8
5M289427 WASHER-HARD (10.2X18.5X2.5-MM THK)8
4J438228 PLUG-PIPE (1/2-14-THD)2
5B263829 BOLT (3/8-16X5.25-IN)2
5M621330 PLUG-PIPE (1/4-18-THD)2
1A596431 BOLT (3/8-16X4.5-IN)1
1F795832 NUT-FULL (1/2-13-THD)4
6N673433 SUPPORT-HOUSING (RH)1
6N673334 SUPPORT-HOUSING (LH)1
245834235 GASKET2
