System And Components
1W-7383 LINES GP-AIRS/N 81Z14501-99999
Group No: 1W-7383
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7N9669 | 1 PIPE-OUTLET | 1 | |
| 5S1188 | 2 SEAL-O-RING | 2 | |
| 1W0481 | 3 RING-EXHAUST SEAL | 2 | |
| 1W7384 | 4 COUPLING | 1 | |
| 4N1010 | 5 SUPPORT-ELBOW | 1 | |
| 1A2029 | 6 BOLT (3/8-16X1.125-IN) | 2 | |
| 0S1590 | 7 BOLT (3/8-16X2-IN) | 2 | |
| 4N6143 | 8 SPACER-SPECIAL (14-MM THK) | 1 | |
| 6L8562 | 9 STUD-TAPERLOCK (3/8-16X1.77-IN) | 4 | |
| 2N2766 | 10 LOCKNUT (3/8-16-THD) | 7 | |
| 2N2765 | 11 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 3 | |
| 7E3904 | 12 TUBE (EXHAUST LH) | 1 | |
| 2W0796 | 13 SUPPORT-EXHAUST PIPE | 1 | |
| 9F8596 | 14 LUG | 2 | |
| 8N0878 | 15 CLAMP | 2 | |
| 8N0879 | 16 CLAMP | 4 | |
| 1D4706 | 17 BOLT (3/8-16X6-IN) | 1 | |
| 4N6145 | 18 SUPPORT-MANIFOLD | 1 | |
| 0S1608 | 19 BOLT (3/8-16X3.75-IN) | 3 | |
| 7L0520 | 20 STUD-TAPERLOCK (3/8-16X1.968-IN) | 4 | |
| 0S1591 | 21 BOLT (3/8-16X1.5-IN) | 6 | |
| 2W7553 | 22 MANIFOLD | 1 | |
| 1069408 | 23 SEAL-EXHAUST | 1 | |
| 5B7890 | 24 PLUG-PIPE | 2 | |
| 0S1594 | 25 BOLT (3/8-16X1-IN) | 6 | |
| 5M2894 | 26 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 4N2565 | 27 PLATE-MANIFOLD | 1 | |
| 4N2564 | GASKET | 1 | |
| 7W6492 | 28 PLUG-PIPE (1/2-14-THD) | 1 | |
| 8T6765 | 29 PLUG-PIPE (1/4-18-THD) | 3 | |
| 9N1081 | 30 ADAPTER-TRANSFER PIPE | 1 | |
| 6N2331 | GASKET | 1 | |
| 4L8337 | 31 SEAL-O-RING | 2 | |
| 7E3901 | 32 TUBE (EXHAUST) | 1 | |
| 7E3902 | 33 TUBE (EXHAUST RH) | 1 | |
| 7E3903 | 34 TUBE | 1 |
