System And Components
8N-8623 LINES GP-AIRS/N 81Z16612-99999
Group No: 8N-8623
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1228432 | 1 ELBOW-EXHAUST | 1 | |
| 1228433 | 2 ELBOW-EXHAUST | 1 | |
| 8N0879 | 3 CLAMP | 4 | |
| 6I2855 | 4 TUBE AS (EXHAUST RH) | 1 | |
| 1332232 | 5 TUBE AS (EXHAUST LH) | 1 | |
| 6N7152 | 6 SUPPORT-ELBOW | 1 | |
| 6N7149 | 7 SUPPORT-ELBOW | 1 | |
| 3N3368 | 8 PIPE-EXHAUST | 1 | |
| 7N2277 | 9 COUPLING-EXHAUST | 2 | |
| 1A5183 | 10 BOLT (3/8-16X4.75-IN) | 3 | |
| 4N1849 | 11 TUBE-AIR | 2 | |
| 5P5700 | 12 SEAL-O-RING | 8 | |
| 4N8523 | 13 PIPE-OUTLET (LH) | 1 | |
| 4N8677 | 14 PIPE-OUTLET (RH) | 1 | |
| 0S1587 | 15 BOLT (1/2-13X1.75-IN) | 4 | |
| 0S1591 | 16 BOLT (3/8-16X1.5-IN) | 4 | |
| 2M8411 | 17 STUD-TAPERLOCK (80-MM) | 1 | |
| 9S8752 | 18 NUT-FULL (3/8-16-THD) | 3 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 10 | |
| 0S1608 | 20 BOLT (3/8-16X3.75-IN) | 2 | |
| 0L1143 | 21 BOLT (3/8-16X2.5-IN) | 4 | |
| 9F8999 | 22 BOLT (3/8-16X7-IN) | 1 | |
| 0S1619 | 23 BOLT (3/8-16X3-IN) | 4 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 14 | |
| 7W6492 | 25 PLUG-PIPE (1/2-14-THD) | 1 | |
| 5B2638 | 26 BOLT (3/8-16X5.25-IN) | 2 | |
| 5B7890 | 27 PLUG-PIPE | 2 | |
| 1A5964 | 28 BOLT (3/8-16X4.5-IN) | 1 | |
| 1F7958 | 29 NUT-FULL (1/2-13-THD) | 4 | |
| 6N6734 | 30 SUPPORT-HOUSING (RH) | 1 | |
| 6N6733 | 31 SUPPORT-HOUSING (LH) | 1 | |
| 2458342 | 32 GASKET (ADAPTER) | 2 | |
| 0L2070 | 33 BOLT (3/8-16X2.25-IN) | 2 | |
| 0T0573 | 34 BOLT (3/8-16X2.75-IN) | 3 | |
| 0L1352 | 35 BOLT (3/8-16X3.25-IN) | 4 | |
| 7N9667 | 36 ELBOW | 1 | |
| 8T6765 | 37 PLUG-PIPE (1/4-18-THD) | 3 | |
| 4N1848 | 38 GASKET | 1 | |
| 6N3543 | 39 PLATE-MANIFOLD | 1 | |
| 4N2564 | 40 GASKET | 1 | |
| 0S1594 | 41 BOLT (3/8-16X1-IN) | 6 | |
| 2A4639 | 42 BOLT (3/8-16X1.625-IN) | 8 | |
| 4J4382 | 43 PLUG-PIPE (1/2-14-THD) | 2 |
