System And Components
Assembly
100%

7W-1077 LINES GP-FUEL FILTERS/N 81Z27796-99999

Group No: 7W-1077
Part NumberPart NameQty
4W19681 DAMPER-SURGE1
6H71272 SPACER (13/32X5/8X9/16-IN THK)1
6K08063 STRAP-CABLE4
6N37974 JUNCTION BLOCK1
6N43765 HOSE AS1
6N43776 HOSE AS1
6N43797 HOSE AS1
8N39628 BRACKET AS-FUEL FILTER1
6N3278BRACKET1
8P51159 BRACKET1
103748110 HOSE AS1
191780511 ELBOW AS3
0307947ADAPTER-ELBOW1
2147568SEAL-O-RING1
349838312 ADAPTER AS1
7J4026ELBOW1
2147568SEAL-O-RING1
0L114313 BOLT (3/8-16X2.5-IN)1
0L135114 BOLT (3/8-16X0.875-IN)4
0L135215 BOLT (3/8-16X3.25-IN)1
0S158816 BOLT (3/8-16X1.25-IN)2
0S159117 BOLT (3/8-16X1.5-IN)1
0S160818 BOLT (3/8-16X3.75-IN)1
0S161919 BOLT (3/8-16X3-IN)1
0T006520 BOLT (3/8-16X3.5-IN)1
1A596421 BOLT (3/8-16X4.5-IN)1
214756622 SEAL-O-RING2
244371223 PLUG AS1
9S4191PLUG (9/16-18-THD)1
2147568SEAL-O-RING1
2F496724 SPACER (10.5X19X5.512-MM THK)2
309513025 PLUG AS1
9S4182PLUG (7/16-20-THD)1
2147566SEAL-O-RING1
353510326 ADAPTER AS1
0307942ELBOW1
2147568SEAL-O-RING1
353510827 ELBOW AS2
2P7214ADAPTER-ELBOW1
2147568SEAL-O-RING1
3B191528 BOLT (3/8-16X1.375-IN)1
4B404329 BOLT (5/8-11X1.375-IN)4
4D773330 CLIP (LOOP)1
5M289431 WASHER-HARD (10.2X18.5X2.5-MM THK)12
5P824732 WASHER-HARD (17X32X3.5-MM THK)4
6K919433 ELBOW1
6V834934 TEE-O-RING PORT1
6W667235 SPACER (10.5X20X38-MM THK)2
7D723336 CLIP (LOOP)(LOOP)3
8M277337 CLIP (LOOP)(LOOP)2
9S875238 NUT-FULL (3/8-16-THD)3
9X645839 WASHER-HARD (10.2X22.5X3-MM THK)3
6K080640 STRAP-CABLE1
0S159141 BOLT (3/8-16X1.5-IN)1
