123-5300 FENDER GPS/N 6PR1-UP

Group No: 123-5300
Part NumberPart NameQty
8C44361 BOLT (1/2-13X1.375-IN)8
12879142 STEP AS2
8W48463 BRACKET AS2
8T93994 BOLT (3/4-10X2.25-IN)38
6V81825 NUT (3/4-10-THD)38
8C68576 BOLT (3/4-10X2.75-IN)8
4T71207 BRACKET (LH)1
4T71198 BRACKET (RH)1
12879139 FENDER AS (LH)1
6C3680RIVET-POP24
8W0527TREAD AS1
8W5190HANDLE1
1435468TREAD AS1
1242812TREAD1
128791210 FENDER AS (RH)1
6C3680RIVET-POP24
8W0527TREAD AS1
8W5190HANDLE1
1435468TREAD AS1
1242812TREAD1
8T499411 WASHER-HARD (20X36.5X3.5-MM THK)92
129771912 FENDER AS (RH)1
8F9836BOSS (3/8-16-THD)1
129772013 FENDER AS (LH)1
8F9836BOSS (3/8-16-THD)1
8W768814 SUPPORT AS (RH)1
8W770915 SUPPORT AS (LH)1
8T939816 BOLT (3/4-10X1.75-IN)8
1K687217 LOCKNUT (1/2-13-THD)8
8T422318 WASHER-HARD (13.5X25.5X3-MM THK)16
