Assembly
100%

125-5044 RADIATOR GPS/N 7CS1-UP

Group No: 125-5044
Part NumberPart NameQty
23050191 TANK AS-RADIATOR (TOP)1
5M19321A STUD-TAPERLOCK (1/2-13X2.17-IN)1
20998762 GASKET2
7N24133 STRIP4
5S73834 BOLT (3/8-16X1.75-IN)22
4L93375 BOLT (3/8-16X1.5-IN)38
8T25016 BOLT (3/8-16X2-IN)14
9B72377 BOLT (3/8-16X1.25-IN)9
12550368 TANK AS-RADIATOR (BOTTOM)1
7N33269 BAFFLE AS8
6B4594RIVET1
7N3324STRIP-BACKING1
7N241210 STRIP2
125503811 STRIP4
125503712 STRIP4
7N226313 BRACKET AS4
7M779413A STUD-WELD (9.4X21.5X25.5-MM)4
6V880114 NUT (3/8-16-THD)17
8T489615 WASHER-HARD (10.2X18.5X2.5-MM THK)132
5M306216 BOLT (3/8-16X0.75-IN)8
150629617 CORE AS-RADIATOR1
7X028918 BOLT (3/8-16X1.875-IN)16
125503319 CHANNEL AS1
1F075019A NUT-WELD (3/8-16-THD)18
2V740219B BOSS (3/8-16 THD)2
125503420 CHANNEL AS1
1F075020A NUT-WELD (3/8-16-THD)20
6K219820B BOSS (3/8-16X1-IN)(3/8-16 THD)2
7N207620C PLATE AS1
127625821 PLATE1
128049622 PLATE1
5S738223 BOLT (3/8-16X1.375-IN)3
1B257824 NUT (3/8-16-THD)6
8T539025 BOLT (3/8-16X3.5-IN)6
5P107526 WASHER-HARD (10.2X22.5X3-MM THK)1
038396727 BRACKET1
