System And Components
203-7962 RADIATOR GPS/N 7CS1-UP
Group No: 203-7962
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7X0328 | 1 BOLT (1/2-13X3.5-IN) | 4 | |
| 8T4223 | 2 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 8C4436 | 3 BOLT (1/2-13X1.375-IN) | 8 | |
| 5M3062 | 4 BOLT (3/8-16X0.75-IN) | 42 | |
| 8T4896 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 72 | |
| 8H8754 | 6 GASKET | 1 | |
| 6C3241 | 7 BOLT (1/2-13X1.5-IN) | 2 | |
| 7E1378 | 8 ELBOW-OUTLET | 1 | |
| 6V4432 | 9 BOLT (1/2-13X4-IN) | 4 | |
| 8M7066 | 10 GASKET | 1 | |
| 8T6767 | 11 PLUG-PIPE (3/8-18-THD) | 1 | |
| 8M7057 | 12 ADAPTER-PLUG | 1 | |
| 6N9590 | 13 PLUG-DRAIN (RADIATOR) | 1 | |
| 7W6492 | 14 PLUG-PIPE (1/2-14-THD) | 1 | |
| 6V8188 | 15 NUT (1/2-13-THD) | 2 | |
| 2S1212 | 16 MOUNT | 2 | |
| 8T4986 | 17 CLAMP-HOSE | 4 | |
| 3718952 | 18 HOSE (18-CM EACH) | ||
| 4N1418 | 19 GASKET-RADIATOR INLET | 2 | |
| 7N3316 | 20 SHIELD AS | 2 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 4 | |
| 7N7988 | 21 MOUNT | 2 | |
| 7N1639 | 22 CAP | 2 | |
| 7N3311 | 23 SUPPORT | 2 | |
| 7N3323 | 24 BAFFLE | 3 | |
| 8T2502 | 25 BOLT (3/8-16X1.125-IN) | 29 | |
| 7N3310 | 26 STRIP-FAN BAFFLE | 3 | |
| 1K4649 | 27 SPACER (0.516X1X1-IN THK) | 4 | |
| 8T4835 | 28 BOLT (1/2-13X2-IN) | 4 | |
| 9S7325 | 29 CLAMP AS | 2 | |
| 8T9101 | 30 BOLT (3/8-16X2.75-IN) | 2 | |
| 8C6871 | 31 CONNECTOR | 1 | |
| 8T9377 | 32 BOLT (3/8-16X2.25-IN) | 2 | |
| 8N9903 | 33 TUBE AS | 1 | |
| 4D7735 | 34 CLIP | 2 | |
| 3718946 | 35 HOSE (13-CM EACH) | ||
| 3718946 | 35A HOSE (16-CM EACH) | ||
| 8T4984 | 36 CLAMP-HOSE | 8 | |
| 1012722 | 37 TUBE AS | 1 | |
| 8T6765 | 38 PLUG-PIPE (1/4-18-THD) | 1 | |
| 6N1981 | 39 CAP AS-COOLANT TANK (RADIATOR) | 1 | |
| 2P3230 | GASKET | 1 | |
| 2S2846 | RETAINER-GASKET | 1 | |
| 7S7807 | INSERT-HELI-COIL | 1 | |
| 9S9979 | RING-RETAINING | 1 | |
| 5S5080 | 40 BOLT (5/16-18X1.5-IN) | 5 | |
| 8T4224 | 41 WASHER-HARD (8.8X16X2-MM THK) | 5 | |
| 5S1211 | 42 COVER-RELIEF VALVE | 1 | |
| 5S1218 | 43 VALVE AS-PRESSURE RELIEF (RADIATOR) | 1 | |
| 5S4629 | 44 GASKET-VALVE | 2 | |
| 5S1213 | 45 PLATE-PRESSURE VALVE | 1 | |
| 2462641 | 46 PADLOCK GP (RADIATOR GUARD) | 1 | |
| 5P8500 | KEY | 1 | |
| 8N9901 | 47 TUBE AS | 2 | |
| 7E1377 | 48 TUBE | 1 | |
| 1255044 | 49 RADIATOR GP | 1 | |
| 1255052 | 50 CHANNEL AS-TOP | 1 | |
| 1255054 | 51 CHANNEL AS-BOTTOM | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 8 | |
| 5P5902 | SEAL (0.2-M) | ||
| 1255051 | 52 CHANNEL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 10 | |
| 5P1075 | 53 WASHER-HARD (10.2X22.5X3-MM THK) | 18 | |
| 1255047 | 54 SHIELD AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 4 | |
| 1255046 | 55 SHIELD AS | 1 | |
| 9F2978 | NUT-WELD (3/8-16-THD) | 4 | |
| 1286600 | 57 CHANNEL AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 10 | |
| 1291359 | 58 STRIP-FAN BAFFLE | 1 | |
| 1286597 | 59 BAFFLE | 1 | |
| 1415937 | 60 BRACKET AS | 1 | |
| 5P1076 | 61 WASHER-HARD (13.5X30X4-MM THK) | 8 | |
| 9X7408 | 62 SEAL-O-RING | 2 | |
| 6V9851 | 63 ELBOW | 1 | |
| 1W3601 | 66 GASKET | 1 | |
| 2299510 | 67 GAUGE GP-COOLANT LEVEL | 1 | |
| 1W3601 | GASKET | 1 | |
| 2F7306 | SCREW-MACHINE (6-32X0.25-IN) | 2 | |
| 1031684 | DIAL | 1 | |
| 5C7883 | 68 BOLT-SOCKET HEAD (M6X1X16-MM) | 4 | |
| 8T4205 | 69 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5S7379 | 70 BOLT (3/8-16X0.875-IN) | 15 |
