System And Components
235-3966 LINES GP-AIRS/N 5JJ1-UP
Group No: 235-3966
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E7424 | 1 CLAMP-HOSE | 1 | |
| 4N2564 | 2 GASKET | 1 | |
| 7W3145 | 4 PLATE | 3 | |
| 1078618 | 5 SENSOR GP-TEMPERATURE (AIR TO AIR AFTERCOOLER) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 3 | |
| 1124550 | SLEEVE (31-CM) | ||
| 2162763 | 6 ADAPTER-AIR | 1 | |
| 2164041 | 7 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 7T1099 | LINK | 2 | |
| 2353967 | 8 ELBOW | 1 | |
| 2353968 | 9 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 0S1588 | 10 BOLT (3/8-16X1.25-IN) | 3 | |
| 7F3425 | 11 BOLT (3/8-16X5.75-IN) | 10 | |
| 3K0360 | 12 SEAL-O-RING | 1 | |
| 4F0411 | 13 BOLT (3/8-16X6.5-IN) | 2 | |
| 5M2894 | 14 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 6L9405 | 15 SEAL-O-RING | 2 | |
| 8F8544 | 16 BOLT (3/8-16X6.25-IN) | 2 | |
| 8L2786 | 17 SEAL-O-RING | 1 | |
| 8T6765 | 18 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S4185 | 19 PLUG (3/4-16-THD) | 1 |
