System And Components
136-1813 LINES GP-FUELS/N 7CS1-UP
Group No: 136-1813
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1240174 | 1 CLIP (LOOP) | 1 | |
| 3K0360 | 2 SEAL-O-RING | 2 | |
| 6V8721 | 3 ELBOW | 1 | |
| 2M9780 | 4 SEAL-O-RING | 1 | |
| 3S2093 | 5 STRAP-CABLE | 1 | |
| 5K5338 | 6 CLIP (LOOP) | 9 | |
| 5M3062 | 7 BOLT (3/8-16X0.75-IN) | 5 | |
| 8T4896 | 8 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8T5429 | 9 ELBOW | 1 | |
| 3D2824 | 10 SEAL-O-RING | 2 | |
| 6V8358 | 11 VALVE-BALL (MANUAL SHUTOFF)(FUEL SHUTOFF) | 1 | |
| 6V9002 | 12 ELBOW | 1 | |
| 6V8398 | 13 SEAL-O-RING | 5 | |
| 6V8625 | 14 ELBOW | 1 | |
| 6V9873 | 15 CONNECTOR | 1 | |
| 3J1907 | 16 SEAL-O-RING | 1 | |
| 1862775 | 17 HOSE AS | 1 | |
| 1862776 | 18 HOSE AS | 1 | |
| 1283130 | 19 BRACKET AS | 1 | |
| 5S7382 | 20 BOLT (3/8-16X1.375-IN) | 2 | |
| 5P1075 | 21 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 6V8801 | 22 NUT (3/8-16-THD) | 2 | |
| 5S7379 | 23 BOLT (3/8-16X0.875-IN) | 2 | |
| 8C6959 | 24 HOSE (85-CM) | ||
| 1S0994 | 25 CLIP (LOOP) | 2 |
