System And Components
137-6424 BATTERY & WIRING GP -COLD WEATHERS/N 7CS1-480
Group No: 137-6424
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X9730 | 1 BATTERY GP (12-VOLT) | 2 | |
| 3S2093 | 2 STRAP-CABLE | 3 | |
| 4K3094 | 3 STUD (3/8-16X10.49-IN) | 4 | |
| 6V8801 | 4 NUT (3/8-16-THD) | 4 | |
| 8T4896 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 40 | |
| 1590981 | 6 SUPPORT AS | 1 | |
| 8D3508 | 6A BOSS (3/8-16X1-IN) | 3 | |
| 8G0452 | 6B LUG (3/8-16-THD) | 1 | |
| 3D6751 | 6C LUG | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 4P8134 | 7 CLIP (LADDER) | 1 | |
| 5P6264 | 8 GROMMET | 3 | |
| 1590984 | 9 COVER | 2 | |
| 1592993 | 10 CABLE AS | 1 | |
| 5P0761 | CABLE (00-GA, RED)(383CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 9X9825 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 8W6445 | 11 HOLD-DOWN AS-BATTERY | 2 | |
| 1592994 | 12 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(82CM) | ||
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1592995 | 13 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(390CM) | ||
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1590986 | 14 SUPPORT AS | 1 | |
| 1F0750 | 14A NUT-WELD (3/8-16-THD) | 2 | |
| 1614423 | 14B LATCH AS | 2 | |
| 1600266 | 15 SUPPORT AS | 1 | |
| 1614423 | 15A LATCH AS | 2 | |
| 9M8406 | 16 CLIP (LOOP) | 21 | |
| 5M3062 | 17 BOLT (3/8-16X0.75-IN) | 3 | |
| 5S7379 | 18 BOLT (3/8-16X0.875-IN) | 29 | |
| 7K1181 | 19 STRAP-CABLE | 8 | |
| 1183534 | 20 SWITCH GP-MAGNETIC (24-VOLT)(START RELAY) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 5C2890 | NUT (M6X1-THD) | 2 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 9X1386 | SLEEVE (16CM) | ||
| 1179081 | SWITCH AS-MAGNETIC (24-VOLT) | 1 | |
| 5S7349 | 21 BOLT (1/4-20X0.5-IN) | 2 | |
| 8T4205 | 22 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 1160118 | 23 CLIP | 1 | |
| 5P4115 | 24 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 1H3338 | 25 LOCKWASHER | 2 | |
| 4P7581 | 26 CLIP (LADDER) | 2 | |
| 6V4611 | 27 FILM-WARNING (JUMP START, READ OMM) | 1 | |
| 3K6060 | 28 LOCKNUT (3/8-16-THD) | 4 | |
| 1434792 | 29 BUMPER | 8 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 |
