System And Components
137-6424 BATTERY & WIRING GP -COLD WEATHERS/N 7CS481-UP
Group No: 137-6424
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 3 | |
| 4K3094 | 2 STUD (3/8-16X10.49-IN) | 4 | |
| 6V4611 | 3 FILM-WARNING (JUMP START, READ OMM) | 1 | |
| 7K1181 | 4 STRAP-CABLE | 8 | |
| 1160118 | 5 CLIP | 1 | |
| 1434792 | 6 BUMPER | 8 | |
| 9X9730 | 7 BATTERY GP (12-VOLT) | 2 | |
| 7N0060 | VENT AS | 6 | |
| 1590984 | 8 COVER | 2 | |
| 1590986 | 9 SUPPORT AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 2 | |
| 1614423 | LATCH AS | 2 | |
| 1592995 | 10 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(390-CM) | ||
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 1600266 | 11 SUPPORT AS | 1 | |
| 1614423 | LATCH AS | 2 | |
| 1879167 | 12 SUPPORT AS | 1 | |
| 8D3508 | BOSS (3/8-16X1-IN) | 3 | |
| 8G0452 | LUG (3/8-16-THD) | 1 | |
| 3D6751 | LUG | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 4 | |
| 1927887 | 13 GUARD | 1 | |
| 2303447 | 14 CABLE AS | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(105-CM) | ||
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 2817780 | 15 CABLE AS | 1 | |
| 1598049 | CABLE (00-GA, RED)(53-CM) | ||
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 9X5699 | BOOT | 1 | |
| 9X9825 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 1183534 | 16 SWITCH GP-MAGNETIC (24-VOLT)(STARTER RELAY) | 1 | |
| 1745907 | 17 CLIP | 22 | |
| 1H3338 | 18 LOCKWASHER | 2 | |
| 2841216 | 19 CABLE AS | 1 | |
| 1598049 | CABLE (00-GA, RED)(321-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 1M6119 | BOLT (5/16-18X1.375-IN) | 1 | |
| 1M6120 | NUT (5/16-18-THD) | 1 | |
| 3K6060 | 20 LOCKNUT (3/8-16-THD) | 4 | |
| 4P7581 | 21 CLIP (LADDER) | 2 | |
| 4P8134 | 22 CLIP (LADDER) | 1 | |
| 5M3062 | 23 BOLT (3/8-16X0.75-IN) | 3 | |
| 5P1075 | 24 WASHER-HARD (10.2X22.5X3-MM THK) | 7 | |
| 5P2228 | 25 BOLT (1/2-13X1-IN) | 2 | |
| 5P4115 | 26 WASHER-HARD (7.2X19X2-MM THK) | 1 | |
| 5P6264 | 27 GROMMET | 3 | |
| 5S7349 | 28 BOLT (1/4-20X0.5-IN) | 2 | |
| 5S7379 | 29 BOLT (3/8-16X0.875-IN) | 32 | |
| 6K8178 | 30 CLIP (LOOP) | 2 | |
| 6V8188 | 31 NUT (1/2-13-THD) | 6 | |
| 6V8801 | 32 NUT (3/8-16-THD) | 4 | |
| 8C6358 | 33 BLOCK AS-JUNCTION (BATTERY) | 1 | |
| 8T3519 | BOLT-BRONZE (1/2-13X2-IN) | 3 | |
| 1D5117 | NUT-JAM (1/2-13-THD) | 3 | |
| 8T2502 | 34 BOLT (3/8-16X1.125-IN) | 1 | |
| 8T4205 | 35 WASHER-HARD (7.2X14.5X2-MM THK) | 1 | |
| 8T4223 | 36 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4896 | 37 WASHER-HARD (10.2X18.5X2.5-MM THK) | 37 | |
| 8W6445 | 38 HOLD-DOWN AS-BATTERY | 2 |
